GWS - 2215/12T
Specifications
- Type: Outrunner
- Weight: 57.00g (2.01oz)
- Maximum Amps: 12
Constants
- kV: 930
- Rm: 0.26
- Io: 0.59
Io Test Data
Dr Kiwi test results
Volts | Amps | RPM |
---|---|---|
10.015 | 0.59 | 9090 |
Test Data
Dr Kiwi test results
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
---|---|---|---|---|---|---|---|---|---|
GWS RS 9x4.7 | 1 | 7 | 4.45 | 31 | 5460 | 24.3 | 285 | 10.05 | 84% |
GWS RS 9x4.7 | 1 | 7.9 | 5.3 | 41 | 6060 | 27.0 | 354 | 12.49 | 82% |
GWS RS 9x4.7 | 1 | 8.9 | 6.3 | 56 | 6720 | 29.9 | 424 | 14.96 | 81% |
GWS RS 9x4.7 | 1 | 9.9 | 7.35 | 72 | 7320 | 32.6 | 500 | 17.64 | 80% |
GWS RS 9x4.7 | 1 | 10.9 | 8.35 | 91 | 7920 | 35.2 | 571 | 20.14 | 78% |
GWS RS 9x4.7 | 1 | 11.1 | 8.65 | 96 | 8010 | 35.6 | 579 | 20.42 | 78% |
GWS HD 9x5 | 1 | 6.9 | 4.3 | 29 | 5460 | 25.9 | 297 | 10.48 | 85% |
GWS HD 9x5 | 1 | 7.9 | 5.25 | 41 | 6090 | 28.8 | 375 | 13.23 | 83% |
GWS HD 9x5 | 1 | 8.9 | 6.3 | 56 | 6720 | 31.8 | 461 | 16.26 | 81% |
GWS HD 9x5 | 1 | 9.9 | 7.3 | 72 | 7290 | 34.5 | 546 | 19.26 | 79% |
GWS HD 9x5 | 1 | 10.9 | 8.45 | 92 | 7860 | 37.2 | 636 | 22.43 | 78% |
GWS HD 9x5 | 1 | 11.1 | 8.75 | 97 | 7980 | 37.8 | 657 | 23.17 | 77% |
GWS HD 9x5 | 1 | 14.4 | 12.8 | 184 | 9600 | 45.5 | 970 | 34.22 | 72% |
GWS RS 3-blade 9x7 | 1 | 6.9 | 7.05 | 48 | 4720 | 31.3 | 346 | 12.20 | 74% |
GWS RS 3-blade 9x7 | 1 | 7.9 | 8.45 | 66 | 5220 | 34.6 | 419 | 14.78 | 71% |
GWS RS 3-blade 9x7 | 1 | 8.9 | 9.9 | 88 | 5660 | 37.5 | 495 | 17.46 | 68% |
GWS RS 3-blade 9x7 | 1 | 9.9 | 11.3 | 111 | 6080 | 40.3 | 573 | 20.21 | 66% |
GWS RS 3-blade 9x7 | 1 | 10.9 | 12.8 | 139 | 6420 | 42.6 | 642 | 22.65 | 63% |
GWS RS 9x7 | 1 | 6.9 | 7.05 | 48 | 4800 | 31.8 | 344 | 12.13 | 75% |
GWS RS 9x7 | 1 | 7.9 | 8.45 | 66 | 5250 | 34.8 | 417 | 14.71 | 71% |
GWS RS 9x7 | 1 | 8.9 | 10.05 | 89 | 5700 | 37.8 | 494 | 17.43 | 69% |
GWS RS 9x7 | 1 | 9.9 | 11.6 | 114 | 6060 | 40.2 | 564 | 19.89 | 66% |
GWS RS 9x7 | 1 | 10.9 | 13.3 | 144 | 6330 | 42.0 | 615 | 21.69 | 62% |
GWS HD 9x7.5 | 1 | 6.9 | 6.35 | 43 | 4920 | 34.9 | 293 | 10.34 | 77% |
GWS HD 9x7.5 | 1 | 7.9 | 7.75 | 61 | 5460 | 38.8 | 361 | 12.73 | 74% |
GWS HD 9x7.5 | 1 | 8.9 | 9.2 | 81 | 5940 | 42.2 | 432 | 15.24 | 72% |
GWS HD 9x7.5 | 1 | 9.9 | 10.7 | 105 | 6390 | 45.4 | 497 | 17.53 | 69% |
GWS HD 9x7.5 | 1 | 10.9 | 12.1 | 131 | 6750 | 47.9 | 562 | 19.82 | 67% |
GWS RS 10x4.7 | 1 | 6.9 | 6.7 | 46 | 4860 | 21.6 | 414 | 14.60 | 76% |
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
GWS RS 10x4.7 | 1 | 7.9 | 8.1 | 63 | 5340 | 23.8 | 509 | 17.95 | 73% |
GWS RS 10x4.7 | 1 | 8.9 | 9.5 | 84 | 5790 | 25.8 | 603 | 21.27 | 70% |
GWS RS 10x4.7 | 1 | 9.9 | 10.85 | 107 | 6180 | 27.5 | 696 | 24.55 | 67% |
GWS RS 10x4.7 | 1 | 10.9 | 12.4 | 135 | 6570 | 29.2 | 794 | 28.01 | 65% |
GWS RS 10x4.7 | 1 | 11.1 | 13 | 144 | 6720 | 29.9 | 826 | 29.14 | 65% |
GWS HD 10x6 | 1 | 6.9 | 5.65 | 38 | 5100 | 29.0 | 366 | 12.91 | 79% |
GWS HD 10x6 | 1 | 7.9 | 6.9 | 54 | 5670 | 32.2 | 457 | 16.12 | 77% |
GWS HD 10x6 | 1 | 8.9 | 8.2 | 72 | 6210 | 35.3 | 551 | 19.44 | 75% |
GWS HD 10x6 | 1 | 9.9 | 9.5 | 94 | 6660 | 37.8 | 641 | 22.61 | 72% |
GWS HD 10x6 | 1 | 10.9 | 10.9 | 118 | 7140 | 40.6 | 730 | 25.75 | 70% |
GWS HD 10x6 | 1 | 11.1 | 11 | 122 | 7200 | 40.9 | 742 | 26.17 | 70% |
GWS HD 10x6 | 1 | 14.4 | 15 | 216 | 8400 | 47.7 | 1015 | 35.80 | 63% |
Bruce Abbot test results
Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
---|---|---|---|---|---|---|---|---|---|
APC SF 8x3.8 | 1 | 10.1 | 5.9 | 59 | 7467 | 26.9 | 404 | 14.25 | 79% |
GWS HD 8x6 | 1 | 9.8 | 6.2 | 60 | 7156 | 40.7 | 366 | 12.91 | 79% |
APC E 8x6 | 1 | 9.7 | 6.6 | 64 | 6930 | 39.4 | 387 | 13.65 | 77% |
GWS EP 8x6 | 1 | 9.7 | 6.7 | 64 | 6895 | 39.2 | 419 | 14.78 | 76% |
APC SF 9x4.7 | 1 | 9.7 | 7.6 | 73 | 6706 | 29.9 | 493 | 17.39 | 74% |
GWS EP 9x5 | 1 | 9.8 | 6.6 | 64 | 7063 | 33.4 | 476 | 16.79 | 77% |
GWS EP 10x6 | 1 | 9.7 | 8.8 | 85 | 6376 | 36.2 | 577 | 20.35 | 71% |
Comments
Bruce Abbot on 2009-01-14 02:56:04
This motor has good performance on both 2S and 3S Lipo, or 6 to 10 cells Nixx. The highest efficiency I measured was 74%.
