Suppo - A2826/6
Specifications
- Type: Outrunner
- Weight: 175.00g (6.17oz)
- Diameter: 35.32mm (1.39in)
- Length: 49.75mm (1.96in)
- Shaft Diameter: 5.00mm (0.20in)
- Maximum Amps: 35
Constants
- kV: 820
- Rm: 0.1
- Io: 1.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.4 | 5620 |
| 8 | 1.5 | 6440 |
| 10 | 1.65 | 8040 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 12x6 | 1 | 10.7 | 19.9 | 212 | 6990 | 39.7 | 1363 | 48.08 | 80% |
| APC E 12x6 | 1 | 11.4 | 21 | 239 | 7200 | 40.9 | 1454 | 51.29 | 77% |
| APC E 13x6.5 | 1 | 7.9 | 15.2 | 120 | 5220 | 32.1 | 970 | 34.22 | 81% |
| APC E 13x6.5 | 1 | 11.1 | 26.3 | 291 | 6780 | 41.7 | 1737 | 61.27 | 74% |
| APC E 13x8 | 1 | 7.9 | 17.1 | 135 | 5040 | 38.2 | 991 | 34.96 | 78% |
| APC E 13x8 | 1 | 11 | 28.9 | 317 | 6510 | 49.3 | 1702 | 60.04 | 72% |
| APC E 14x8.5 | 1 | 7.7 | 21 | 161 | 4680 | 37.7 | 1177 | 41.52 | 74% |
| APC E 14x8.5 | 1 | 10.8 | 33.6 | 362 | 5970 | 48.0 | 1954 | 68.93 | 67% |
