TurboPropRC - TP 220150
Specifications
- Type: Outrunner
- Weight: 62.00g (2.19oz)
- Diameter: 27.70mm (1.09in)
- Length: 32.50mm (1.28in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 10.5
Constants
- kV: 800
- Rm: 0.255
- Io: 0.55
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.45 | 5550 |
| 8 | 0.5 | 6300 |
| 10 | 0.55 | 7800 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 7 | 3.15 | 22 | 5010 | 23.7 | 241 | 8.50 | 89% |
| GWS HD 9x5 | 1 | 7.9 | 3.85 | 30 | 5610 | 26.6 | 306 | 10.79 | 89% |
| GWS HD 9x5 | 1 | 8.9 | 4.65 | 41 | 6210 | 29.4 | 381 | 13.44 | 87% |
| GWS HD 9x5 | 1 | 9.9 | 5.45 | 53 | 6810 | 32.2 | 455 | 16.05 | 86% |
| GWS HD 10x6 | 1 | 6.9 | 4.3 | 29 | 4770 | 27.1 | 314 | 11.08 | 86% |
| GWS HD 10x6 | 1 | 7.9 | 5.3 | 41 | 5340 | 30.3 | 393 | 13.86 | 84% |
| GWS HD 10x6 | 1 | 8.9 | 6.3 | 56 | 5850 | 33.2 | 482 | 17.00 | 82% |
| GWS HD 10x6 | 1 | 9.9 | 7.4 | 73 | 6420 | 36.5 | 575 | 20.28 | 81% |
| GWS HD 10x6 | 1 | 10.9 | 8.5 | 92 | 6900 | 39.2 | 667 | 23.53 | 79% |
| GWS HD 11x7 | 1 | 6.9 | 6.15 | 42 | 4440 | 29.4 | 428 | 15.10 | 80% |
| GWS HD 11x7 | 1 | 7.9 | 7.15 | 56 | 4920 | 32.6 | 530 | 18.70 | 78% |
| GWS HD 11x7 | 1 | 8.9 | 8.85 | 78 | 5370 | 35.6 | 643 | 22.68 | 75% |
| GWS HD 11x7 | 1 | 9.9 | 10.3 | 101 | 5820 | 38.6 | 746 | 26.31 | 73% |
| GWS HD 11x7 | 1 | 10.9 | 11.6 | 126 | 6210 | 41.2 | 850 | 29.98 | 71% |
