Westport - 22.7mm, 15T/25ga
Specifications
- Type: Outrunner
- Weight: 22.00g (0.78oz)
- Diameter: 26.60mm (1.05in)
- Length: 11.50mm (0.45in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 8
Constants
- kV: 1790
- Rm: 0.33
- Io: 0.5
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.45 | 12230 |
| 8 | 0.5 | 14000 |
| 10 | 0.5 | 17560 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.75x4.75 | 1 | 6.9 | 3.45 | 23 | 10530 | 47.4 | 103 | 3.63 | 85% |
| APC E 4.75x4.75 | 1 | 7.9 | 4.2 | 33 | 11730 | 52.8 | 126 | 4.44 | 83% |
| APC E 4.75x4.75 | 1 | 8.9 | 5 | 44 | 12900 | 58.0 | 154 | 5.43 | 81% |
| APC E 4.75x4.75 | 1 | 9.9 | 5.95 | 58 | 14100 | 63.4 | 185 | 6.53 | 80% |
| APC E 4.75x4.75 | 1 | 10.9 | 6.9 | 75 | 15120 | 68.0 | 215 | 7.58 | 77% |
| APC E 5x5 | 1 | 7 | 3.95 | 27 | 10290 | 48.7 | 112 | 3.95 | 82% |
| APC E 5x5 | 1 | 7.9 | 4.75 | 37 | 11400 | 54.0 | 137 | 4.83 | 81% |
| APC E 5x5 | 1 | 8.9 | 5.6 | 49 | 12450 | 59.0 | 166 | 5.86 | 78% |
| APC E 5x5 | 1 | 9.9 | 6.7 | 66 | 13590 | 64.3 | 200 | 7.05 | 77% |
| APC E 5x5 | 1 | 10.9 | 7.8 | 85 | 14580 | 69.0 | 233 | 8.22 | 75% |
| APC E (Broad) 5.1x4.5 | 1 | 7 | 4.5 | 31 | 9780 | 41.7 | 166 | 5.86 | 78% |
| APC E (Broad) 5.1x4.5 | 1 | 7.9 | 5.6 | 44 | 10920 | 46.5 | 207 | 7.30 | 77% |
| APC E (Broad) 5.1x4.5 | 1 | 8.9 | 6.7 | 59 | 11850 | 50.5 | 246 | 8.68 | 74% |
| APC E (Broad) 5.1x4.5 | 1 | 9.9 | 8.15 | 80 | 12840 | 54.7 | 294 | 10.37 | 72% |
| APC E (Broad) 5.1x4.5 | 1 | 10.9 | 9.6 | 104 | 13530 | 57.7 | 334 | 11.78 | 69% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 3.85 | 26 | 10350 | 48.0 | 154 | 5.43 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 4.65 | 36 | 11520 | 53.5 | 191 | 6.74 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 5.5 | 48 | 12600 | 58.5 | 228 | 8.04 | 79% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 6.55 | 64 | 13680 | 63.5 | 273 | 9.63 | 77% |
| Zagi Carbon 5.1x4.9 | 1 | 10.9 | 7.7 | 83 | 14730 | 68.3 | 317 | 11.18 | 75% |
| APC E 5.7x3 | 1 | 7 | 3.5 | 24 | 10590 | 30.1 | 153 | 5.40 | 85% |
| APC E 5.7x3 | 1 | 7.9 | 4.2 | 33 | 11760 | 33.4 | 192 | 6.77 | 83% |
| APC E 5.7x3 | 1 | 8.9 | 5 | 44 | 12960 | 36.8 | 235 | 8.29 | 81% |
| APC E 5.7x3 | 1 | 9.9 | 5.9 | 58 | 14040 | 39.9 | 280 | 9.88 | 79% |
| APC E 5.7x3 | 1 | 10.9 | 6.95 | 75 | 15120 | 43.0 | 332 | 11.71 | 77% |
| GWS HD 7x3.5 | 1 | 7 | 4.6 | 32 | 9930 | 32.9 | 244 | 8.61 | 79% |
| GWS EP 7x3.5 | 1 | 7.4 | 5.05 | 37 | 10440 | 34.6 | 274 | 9.67 | 79% |
