Motrolfly - 2210-2200



Specifications

  • Type: Outrunner
  • Weight: 46.00g (1.62oz)
  • Maximum Amps: 25

Constants

  • kV: 2280
  • Rm: 0.09
  • Io: 2.4



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 2.4 22320

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Graupner CAM 4.7x4.7 1 6.9 8.45 58 14280 63.6 199 7.02 91%
Graupner CAM 4.7x4.7 1 7.8 10.1 78 16050 71.4 254 8.96 90%
Graupner CAM 4.7x4.7 1 8.8 12.1 106 17790 79.2 315 11.11 89%
Graupner CAM 4.7x4.7 1 9.8 14.35 140 19440 86.5 376 13.26 87%
Graupner CAM 4.7x4.7 1 10.7 17 181 20820 92.7 435 15.34 85%
Zagi Carbon 5.1x4.9 1 6.9 10.05 69 13980 64.9 285 10.05 89%
Zagi Carbon 5.1x4.9 1 7.8 12.3 95 15600 72.4 359 12.66 88%
Zagi Carbon 5.1x4.9 1 8.8 14.65 128 17190 79.8 438 15.45 86%
Zagi Carbon 5.1x4.9 1 9.7 17.2 166 18690 86.7 515 18.17 85%
Zagi Carbon 5.1x4.9 1 10.7 19.8 211 20130 93.4 603 21.27 83%
Graupner CAM 5.2x5.2 1 6.8 11.6 78 13590 66.9 263 9.28 88%
Graupner CAM 5.2x5.2 1 7.8 14.25 111 15150 74.6 332 11.71 85%
Graupner CAM 5.2x5.2 1 8.7 16.85 146 16620 81.8 400 14.11 84%
Graupner CAM 5.2x5.2 1 9.7 19.6 190 17820 87.8 469 16.54 81%
Graupner CAM 5.2x5.2 1 10.7 22.7 242 19500 96.0 554 19.54 80%
APC E 5.5x4.5 1 7.9 14.2 112 15240 64.9 351 12.38 85%
APC E 5.5x4.5 1 11.6 25.7 298 20340 86.7 664 23.42 77%
APC E 6x4 1 7.8 14.3 111 15180 57.5 486 17.14 85%
APC E 6x4 1 11.6 26.1 302 20280 76.8 890 31.39 77%
APC E 6x5.5 1 7.7 18.6 143 13650 71.1 464 16.37 78%
