GWS - 2208/18T
Specifications
- Type: Outrunner
- Weight: 39.00g (1.38oz)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 12
Constants
- kV: 1050
- Rm: 0
- Io: 0
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 8 | 0.4 | 0 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 14.7 | 5.55 | 81 | 13830 | 45.8 | 466 | 16.44 | 90% |
| GWS HD 8x4 | 1 | 6.9 | 3.25 | 22 | 6510 | 24.7 | 213 | 7.51 | 90% |
| GWS HD 8x4 | 1 | 7.9 | 3.95 | 31 | 7200 | 27.3 | 267 | 9.42 | 87% |
| GWS HD 8x4 | 1 | 8.9 | 4.75 | 42 | 7980 | 30.2 | 325 | 11.46 | 85% |
| GWS HD 8x4 | 1 | 9.9 | 5.5 | 54 | 8670 | 32.8 | 382 | 13.47 | 83% |
| GWS HD 8x4 | 1 | 10.9 | 6.4 | 69 | 9300 | 35.2 | 450 | 15.87 | 81% |
| GWS HD 8x4 | 1 | 11.1 | 6.6 | 73 | 9420 | 35.7 | 456 | 16.08 | 81% |
| GWS HD 8x4 | 1 | 14.7 | 9.8 | 144 | 11250 | 42.6 | 687 | 24.23 | 73% |
| GWS RS 8x4.3 | 1 | 11.1 | 7.9 | 87 | 8670 | 35.3 | 500 | 17.64 | 74% |
| GWS RS 9x4.7 | 1 | 11.1 | 10 | 111 | 6690 | 29.8 | 534 | 18.84 | 57% |
| GWS HD 9x5 | 1 | 6.9 | 5.15 | 35 | 5640 | 26.7 | 308 | 10.86 | 78% |
| GWS HD 9x5 | 1 | 7.9 | 6.1 | 48 | 6150 | 29.1 | 367 | 12.95 | 74% |
| GWS HD 9x5 | 1 | 8.9 | 7.2 | 64 | 6690 | 31.7 | 436 | 15.38 | 72% |
| GWS HD 9x5 | 1 | 9.9 | 8.3 | 82 | 7140 | 33.8 | 504 | 17.78 | 69% |
| GWS HD 9x5 | 1 | 11.1 | 8.95 | 99 | 7470 | 35.4 | 547 | 19.29 | 64% |
| GWS HD 10x6 | 1 | 11.1 | 10 | 111 | 6360 | 36.1 | 540 | 19.05 | 55% |
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 6x3 | 1 | 7.8 | 1.6 | 12 | 8149 | 23.1 | 98 | 3.46 | 99% |
| GWS EP 7x3.5 | 1 | 11 | 3.7 | 40 | 10680 | 35.4 | 281 | 9.91 | 92% |
| APC SF 7x4 | 1 | 10.9 | 6.3 | 68 | 9532 | 36.1 | 395 | 13.93 | 83% |
| APC E 7x5 | 1 | 10.4 | 6.6 | 68 | 8920 | 42.2 | 352 | 12.42 | 82% |
| GWS EP 8x4 | 1 | 7.5 | 3.8 | 28 | 6936 | 26.3 | 243 | 8.57 | 88% |
| GWS EP 8x4 | 1 | 10.5 | 6.5 | 68 | 9022 | 34.2 | 447 | 15.77 | 82% |
| GWS EP 8x4.3 | 1 | 7.4 | 4.3 | 31 | 6626 | 27.0 | 268 | 9.45 | 85% |
| GWS HD 8x6 | 1 | 7.3 | 5.3 | 38 | 6087 | 34.6 | 256 | 9.03 | 79% |
| GWS HD 8x6 | 1 | 10.1 | 8.8 | 88 | 7682 | 43.6 | 435 | 15.34 | 72% |
| GWS EP 8x6 | 1 | 7.2 | 5.8 | 41 | 5883 | 33.4 | 293 | 10.34 | 78% |
| GWS EP 9x4.7 | 1 | 7.2 | 5.9 | 42 | 5772 | 25.7 | 328 | 11.57 | 76% |
| GWS EP 9x5 | 1 | 7.3 | 5.7 | 41 | 5961 | 28.2 | 335 | 11.82 | 78% |
| GWS EP 9x5 | 1 | 9.9 | 9 | 89 | 7384 | 35.0 | 547 | 19.29 | 71% |
| GWS EP 9x7 | 1 | 6.9 | 8 | 55 | 4714 | 31.2 | 320 | 11.29 | 65% |
| GWS EP 9x7 | 1 | 9.9 | 12.2 | 120 | 5658 | 37.5 | 502 | 17.71 | 54% |
| GWS EP 3 blade 9x7 | 1 | 7 | 7.9 | 55 | 4717 | 31.3 | 326 | 11.50 | 64% |
| GWS EP 3 blade 9x7 | 1 | 9.8 | 12.1 | 118 | 5606 | 37.2 | 504 | 17.78 | 54% |
| GWS HD 9x7.5 | 1 | 7 | 7.5 | 52 | 4959 | 35.2 | 286 | 10.09 | 67% |
| GWS HD 9x7.5 | 1 | 9.9 | 11.9 | 117 | 5935 | 42.1 | 442 | 15.59 | 57% |
| APC SF 10x4.7 | 1 | 9.8 | 12.5 | 122 | 5594 | 24.9 | 615 | 21.69 | 54% |
| GWS EP 10x4.7 | 1 | 6.9 | 8.2 | 56 | 4545 | 20.2 | 399 | 14.07 | 63% |
| GWS EP 10x4.7 | 1 | 9.8 | 12.7 | 124 | 5544 | 24.7 | 630 | 22.22 | 54% |
| GWS EP 10x6 | 1 | 7 | 7 | 49 | 5164 | 29.3 | 364 | 12.84 | 70% |
| GWS EP 10x6 | 1 | 10 | 11.3 | 113 | 6418 | 36.5 | 599 | 21.13 | 61% |
