TurboPropRC - TP 220050
Specifications
- Type: Outrunner
- Weight: 33.00g (1.16oz)
- Diameter: 27.70mm (1.09in)
- Length: 23.70mm (0.93in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 7.5
Constants
- kV: 1190
- Rm: 0.4
- Io: 0.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.45 | 8190 |
| 8 | 0.5 | 9330 |
| 10.01 | 0.6 | 11670 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 6.9 | 2 | 13 | 7440 | 24.7 | 120 | 4.23 | 91% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.45 | 19 | 8460 | 28.0 | 159 | 5.61 | 90% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.9 | 25 | 9360 | 31.0 | 199 | 7.02 | 88% |
| GWS HD 7x3.5 | 1 | 10 | 3.4 | 34 | 10290 | 34.1 | 248 | 8.75 | 86% |
| GWS HD 7x3.5 | 1 | 11 | 3.9 | 42 | 11160 | 37.0 | 296 | 10.44 | 85% |
| APC SF 7x6 | 1 | 6.9 | 4.4 | 30 | 6360 | 36.1 | 196 | 6.91 | 77% |
| APC SF 7x6 | 1 | 7.9 | 5.45 | 43 | 6990 | 39.7 | 243 | 8.57 | 74% |
| APC SF 7x6 | 1 | 8.9 | 6.5 | 57 | 7620 | 43.3 | 288 | 10.16 | 72% |
| APC SF 7x6 | 1 | 9.9 | 7.55 | 74 | 8160 | 46.4 | 333 | 11.75 | 69% |
| APC SF 7x6 | 1 | 10.9 | 8.6 | 93 | 8640 | 49.1 | 375 | 13.23 | 67% |
| GWS HD 8x4 | 1 | 6.9 | 3.7 | 25 | 6720 | 25.4 | 234 | 8.25 | 82% |
| GWS HD 8x4 | 1 | 7.9 | 4.5 | 35 | 7500 | 28.4 | 297 | 10.48 | 80% |
| GWS HD 8x4 | 1 | 8.9 | 5.3 | 47 | 8220 | 31.1 | 352 | 12.42 | 78% |
| GWS HD 8x4 | 1 | 9.9 | 6.1 | 60 | 8880 | 33.6 | 418 | 14.74 | 75% |
| GWS HD 8x4 | 1 | 10.9 | 7 | 76 | 9510 | 36.0 | 482 | 17.00 | 73% |
| GWS HD 9x5 | 1 | 6.9 | 5.7 | 39 | 5760 | 27.3 | 327 | 11.53 | 70% |
