GPS - HXT C1826-31
Specifications
- Type: Outrunner
- Weight: 21.00g (0.74oz)
- Maximum Amps: 10
Constants
- kV: 2020
- Rm: 0.75
- Io: 0.45
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.35 | 13680 |
| 8 | 0.4 | 15630 |
| 10 | 0.45 | 19410 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 7 | 2.2 | 15 | 10980 | 41.6 | 70 | 2.47 | 78% |
| GWS HD 4x4 | 1 | 7.4 | 2.35 | 17 | 11520 | 43.6 | 77 | 2.72 | 77% |
| GWS HD 4x4 | 1 | 7.9 | 2.6 | 20 | 12150 | 46.0 | 85 | 3.00 | 76% |
| GWS HD 4x4 | 1 | 8.9 | 3 | 26 | 13290 | 50.3 | 101 | 3.56 | 74% |
| GWS HD 4x4 | 1 | 9.9 | 3.5 | 34 | 14310 | 54.2 | 118 | 4.16 | 72% |
| GWS HD 4x4 | 1 | 10.9 | 3.95 | 43 | 15330 | 58.1 | 135 | 4.76 | 70% |
| GWS HD 5x3 | 1 | 7 | 2.2 | 15 | 10920 | 31.0 | 112 | 3.95 | 77% |
| GWS HD 5x3 | 1 | 7.4 | 2.4 | 17 | 11460 | 32.6 | 125 | 4.41 | 77% |
| GWS HD 5x3 | 1 | 8 | 2.6 | 20 | 12150 | 34.5 | 139 | 4.90 | 75% |
| GWS HD 5x3 | 1 | 8.9 | 3.05 | 27 | 13290 | 37.8 | 167 | 5.89 | 74% |
| GWS HD 5x3 | 1 | 9.9 | 3.5 | 34 | 14370 | 40.8 | 197 | 6.95 | 72% |
| GWS HD 5x3 | 1 | 10.9 | 3.9 | 42 | 15360 | 43.6 | 224 | 7.90 | 70% |
| GWS HD 6x3 | 1 | 7 | 2.95 | 20 | 9720 | 27.6 | 138 | 4.87 | 69% |
| GWS HD 6x3 | 1 | 7.4 | 3.15 | 23 | 10170 | 28.9 | 150 | 5.29 | 68% |
| GWS HD 6x3 | 1 | 7.9 | 3.45 | 27 | 10680 | 30.3 | 167 | 5.89 | 67% |
| GWS HD 6x3 | 1 | 8.9 | 3.95 | 35 | 11550 | 32.8 | 196 | 6.91 | 64% |
| GWS HD 6x3 | 1 | 9.9 | 4.55 | 45 | 12270 | 34.9 | 214 | 7.55 | 61% |
