Atlas - AM 2312/09
Specifications
- Type: Outrunner
- Weight: 60.00g (2.12oz)
- Maximum Amps: 17
Constants
- kV: 960
- Rm: 0.23
- Io: 0.9
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.75 | 6570 |
| 8 | 0.8 | 7530 |
| 10 | 0.9 | 9390 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 2.8 | 19 | 6030 | 22.8 | 187 | 6.60 | 91% |
| GWS HD 8x4 | 1 | 7.9 | 3.35 | 26 | 6810 | 25.8 | 237 | 8.36 | 90% |
| GWS HD 8x4 | 1 | 8.9 | 4.05 | 36 | 7590 | 28.8 | 295 | 10.41 | 89% |
| GWS HD 8x4 | 1 | 9.9 | 4.8 | 47 | 8310 | 31.5 | 360 | 12.70 | 87% |
| GWS HD 8x4 | 1 | 10.9 | 5.5 | 59 | 9030 | 34.2 | 426 | 15.03 | 86% |
| GWS HD 9x5 | 1 | 6.9 | 4.6 | 31 | 5610 | 26.6 | 299 | 10.55 | 85% |
| GWS HD 9x5 | 1 | 7.9 | 5.6 | 44 | 6270 | 29.7 | 377 | 13.30 | 83% |
| GWS HD 9x5 | 1 | 8.9 | 6.7 | 59 | 6930 | 32.8 | 466 | 16.44 | 81% |
| GWS HD 9x5 | 1 | 9.8 | 7.8 | 76 | 7500 | 35.5 | 550 | 19.40 | 80% |
| GWS HD 9x5 | 1 | 10.8 | 9 | 97 | 8400 | 39.8 | 633 | 22.33 | 81% |
| APC SF 9x6 | 1 | 6.8 | 7 | 47 | 4920 | 27.9 | 354 | 12.49 | 75% |
| APC SF 9x6 | 1 | 6.9 | 7.2 | 49 | 4980 | 28.3 | 364 | 12.84 | 75% |
| APC SF 9x6 | 1 | 7.8 | 8.8 | 68 | 5460 | 31.0 | 440 | 15.52 | 73% |
| APC SF 9x6 | 1 | 8.8 | 10.55 | 92 | 5880 | 33.4 | 527 | 18.59 | 70% |
| APC SF 9x6 | 1 | 9.6 | 11.8 | 113 | 6150 | 34.9 | 584 | 20.60 | 67% |
| APC SF 9x6 | 1 | 9.8 | 12.05 | 118 | 6240 | 35.5 | 597 | 21.06 | 66% |
| APC SF 10x4.7 | 1 | 6.8 | 7 | 47 | 4920 | 21.9 | 412 | 14.53 | 75% |
| APC SF 10x4.7 | 1 | 6.9 | 7.2 | 49 | 4980 | 22.2 | 425 | 14.99 | 75% |
| APC SF 10x4.7 | 1 | 7.8 | 8.8 | 68 | 5460 | 24.3 | 521 | 18.38 | 73% |
| APC SF 10x4.7 | 1 | 8.8 | 10.45 | 91 | 5910 | 26.3 | 628 | 22.15 | 70% |
| APC SF 10x4.7 | 1 | 9.5 | 11.35 | 107 | 6150 | 27.4 | 685 | 24.16 | 67% |
| APC SF 10x4.7 | 1 | 9.8 | 12 | 117 | 6270 | 27.9 | 723 | 25.50 | 67% |
| APC SF 10x4.7 | 1 | 10.8 | 13.55 | 146 | 6630 | 29.5 | 809 | 28.54 | 64% |
| GWS HD 10x6 | 1 | 6.9 | 6.05 | 41 | 5250 | 29.8 | 372 | 13.12 | 79% |
| GWS HD 10x6 | 1 | 7.8 | 7.3 | 56 | 5820 | 33.1 | 458 | 16.16 | 78% |
| GWS HD 10x6 | 1 | 8.8 | 8.6 | 75 | 6360 | 36.1 | 548 | 19.33 | 75% |
| GWS HD 10x6 | 1 | 9.8 | 10.15 | 99 | 6900 | 39.2 | 651 | 22.96 | 73% |
| GWS HD 10x6 | 1 | 10.8 | 11.45 | 123 | 7350 | 41.8 | 733 | 25.86 | 71% |
| APC SF 10x7 | 1 | 6.6 | 8.55 | 56 | 4320 | 28.6 | 411 | 14.50 | 68% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC SF 10x7 | 1 | 6.8 | 9.2 | 62 | 4470 | 29.6 | 450 | 15.87 | 68% |
| APC SF 10x7 | 1 | 7.8 | 11.1 | 86 | 4860 | 32.2 | 540 | 19.05 | 65% |
| APC SF 10x7 | 1 | 8.8 | 12.8 | 112 | 5190 | 34.4 | 624 | 22.01 | 61% |
| APC SF 10x7 | 1 | 9.3 | 13.9 | 129 | 5340 | 35.4 | 666 | 23.49 | 60% |
| APC SF 10x7 | 1 | 9.8 | 14.5 | 142 | 5490 | 36.4 | 696 | 24.55 | 58% |
| APC SF 10x7 | 1 | 10.8 | 16.1 | 173 | 5730 | 38.0 | 770 | 27.16 | 55% |
