Scorpion - 2208-34 NEW



Specifications

  • Type: Outrunner
  • Weight: 40.00g (1.41oz)
  • Diameter: 27.88mm (1.10in)
  • Length: 20.55mm (0.81in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 15

Constants

  • kV: 1206
  • Rm: 0
  • Io: 0



Io Test Data

agilitygang test results
Volts Amps RPM
9.6 12.4 4000

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC SF 7x6 1 6.9 4.3 29 6660 37.8 207 7.30 80%
APC SF 7x6 1 7 4.35 30 6660 37.8 209 7.37 79%
APC SF 7x6 1 7.9 5.4 42 7350 41.8 261 9.21 77%
APC SF 7x6 1 7.9 5.4 42 7380 41.9 261 9.21 77%
APC SF 7x6 1 8.9 6.55 58 8040 45.7 315 11.11 75%
APC SF 7x6 1 8.9 6.6 58 8130 46.2 314 11.08 76%
APC SF 7x6 1 9.9 7.8 77 8700 49.4 371 13.09 73%
APC SF 7x6 1 9.9 7.8 77 8700 49.4 371 13.09 73%
APC SF 7x6 1 10.5 8.4 88 9090 51.6 399 14.07 72%
APC SF 7x6 1 10.9 9.1 99 9300 52.8 422 14.89 71%
APC SF 7x6 1 10.9 9.1 99 9330 53.0 429 15.13 71%
GWS HD 8x4 1 7 3.6 25 6840 25.9 240 8.47 81%
GWS HD 8x4 1 7.9 4.5 35 7650 29.0 308 10.86 80%
GWS HD 8x4 1 8.9 5.4 48 8460 32.0 384 13.55 79%
GWS HD 8x4 1 9.9 6.4 63 9210 34.9 460 16.23 77%
GWS HD 8x4 1 10.5 6.9 72 9570 36.2 494 17.43 76%
GWS HD 8x4 1 10.9 7.35 80 9930 37.6 532 18.77 76%
GWS HD 8x6 1 7 5.7 39 6210 35.3 276 9.74 74%
GWS HD 8x6 1 7.9 6.9 54 6840 38.9 336 11.85 72%
GWS HD 8x6 1 8.9 8.25 73 7470 42.4 404 14.25 70%
GWS HD 8x6 1 9.9 9.75 96 8040 45.7 474 16.72 67%
GWS HD 8x6 1 10.5 10.3 108 8310 47.2 502 17.71 66%
GWS HD 8x6 1 10.9 11 119 8550 48.6 532 18.77 65%
GWS HD 9x5 1 6.9 6.05 41 6090 28.8 362 12.77 73%
GWS HD 9x5 1 7.9 7.35 58 6690 31.7 446 15.73 70%
GWS HD 9x5 1 8.9 8.7 77 7260 34.4 535 18.87 68%
GWS HD 9x5 1 9.9 10.15 100 7800 36.9 619 21.83 65%
GWS HD 9x5 1 10.5 10.75 112 8010 37.9 655 23.10 63%
