Motrolfly - 2205-1350
Specifications
- Type: Outrunner
- Weight: 31.00g (1.09oz)
- Maximum Amps: 9
Constants
- kV: 1210
- Rm: 0.42
- Io: 0.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.6 | 11760 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 6.9 | 1.9 | 13 | 7470 | 24.8 | 121 | 4.27 | 89% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.35 | 18 | 8400 | 27.8 | 159 | 5.61 | 88% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.9 | 25 | 9390 | 31.1 | 207 | 7.30 | 87% |
| GWS HD 7x3.5 | 1 | 9.9 | 3.4 | 33 | 10290 | 34.1 | 253 | 8.92 | 86% |
| GWS HD 7x3.5 | 1 | 11 | 4 | 44 | 11190 | 37.1 | 305 | 10.76 | 84% |
| APC SF 7x4 | 1 | 6.9 | 3.15 | 21 | 6960 | 26.4 | 167 | 5.89 | 83% |
| APC SF 7x4 | 1 | 7.9 | 3.85 | 30 | 7710 | 29.2 | 210 | 7.41 | 81% |
| APC SF 7x4 | 1 | 8.9 | 4.6 | 40 | 8430 | 31.9 | 254 | 8.96 | 78% |
| APC SF 7x4 | 1 | 9.9 | 5.5 | 54 | 9120 | 34.5 | 303 | 10.69 | 76% |
| APC SF 7x4 | 1 | 10.9 | 6.5 | 70 | 9840 | 37.3 | 356 | 12.56 | 75% |
| APC E 7x5 | 1 | 6.9 | 3.8 | 26 | 6630 | 31.4 | 195 | 6.88 | 79% |
| APC E 7x5 | 1 | 7.9 | 4.6 | 36 | 7410 | 35.1 | 246 | 8.68 | 78% |
| APC E 7x5 | 1 | 8.9 | 5.45 | 48 | 8070 | 38.2 | 296 | 10.44 | 75% |
| APC E 7x5 | 1 | 9.9 | 6.2 | 61 | 8730 | 41.3 | 348 | 12.28 | 73% |
| APC E 7x5 | 1 | 10.9 | 7.3 | 79 | 9420 | 44.6 | 416 | 14.67 | 71% |
| APC SF 7x6 | 1 | 6.9 | 4.4 | 30 | 6360 | 36.1 | 196 | 6.91 | 76% |
| APC SF 7x6 | 1 | 7.9 | 5.35 | 42 | 7020 | 39.9 | 242 | 8.54 | 73% |
| APC SF 7x6 | 1 | 8.9 | 6.3 | 56 | 7590 | 43.1 | 285 | 10.05 | 70% |
| APC SF 7x6 | 1 | 9.9 | 7.35 | 72 | 8160 | 46.4 | 332 | 11.71 | 68% |
| APC SF 7x6 | 1 | 10.8 | 8.3 | 89 | 8580 | 48.8 | 369 | 13.02 | 66% |
| GWS HD 8x4 | 1 | 7 | 3.75 | 26 | 6720 | 25.4 | 242 | 8.54 | 79% |
| GWS HD 8x4 | 1 | 7.4 | 4.05 | 29 | 7050 | 26.7 | 266 | 9.38 | 79% |
| GWS HD 8x4 | 1 | 7.9 | 4.4 | 34 | 7410 | 28.1 | 294 | 10.37 | 78% |
| GWS HD 8x4 | 1 | 8.9 | 5.3 | 47 | 8160 | 30.9 | 362 | 12.77 | 76% |
| GWS HD 8x4 | 1 | 9.9 | 6.15 | 60 | 8760 | 33.2 | 425 | 14.99 | 73% |
| GWS HD 8x4 | 1 | 10.9 | 7.2 | 78 | 9420 | 35.7 | 494 | 17.43 | 71% |
| GWS RS 8x4.3 | 1 | 6.9 | 4.7 | 32 | 6300 | 25.6 | 274 | 9.67 | 75% |
| GWS RS 8x4.3 | 1 | 7.9 | 5.55 | 43 | 6900 | 28.1 | 332 | 11.71 | 72% |
| GWS RS 8x4.3 | 1 | 8.9 | 6.5 | 57 | 7530 | 30.7 | 392 | 13.83 | 70% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 8x4.3 | 1 | 9.9 | 7.45 | 73 | 8100 | 33.0 | 455 | 16.05 | 68% |
| GWS RS 8x4.3 | 1 | 10.9 | 8.3 | 90 | 8580 | 34.9 | 511 | 18.02 | 65% |
| APC SF 9x4.7 | 1 | 7 | 6.25 | 43 | 5610 | 25.0 | 341 | 12.03 | 66% |
| APC SF 9x4.7 | 1 | 7.4 | 6.7 | 49 | 5820 | 25.9 | 367 | 12.95 | 65% |
| GWS RS 9x4.7 | 1 | 7 | 6.75 | 47 | 5220 | 23.2 | 348 | 12.28 | 62% |
| GWS RS 9x4.7 | 1 | 7.4 | 7.4 | 54 | 5460 | 24.3 | 379 | 13.37 | 61% |
| GWS HD 9x5 | 1 | 7 | 5.8 | 40 | 5790 | 27.4 | 333 | 11.75 | 68% |
| GWS HD 9x5 | 1 | 7.4 | 6.2 | 45 | 6000 | 28.4 | 359 | 12.66 | 67% |
| GWS HD 9x5 | 1 | 7.9 | 6.75 | 53 | 6240 | 29.6 | 396 | 13.97 | 65% |
| GWS HD 9x5 | 1 | 8.9 | 7.9 | 70 | 6720 | 31.8 | 465 | 16.40 | 62% |
| GWS HD 9x5 | 1 | 9.9 | 9 | 89 | 7110 | 33.7 | 528 | 18.62 | 59% |
