LightFlightRC - 28-37-2 U. Black
Specifications
- Type: Inrunner
- Weight: 83.00g (2.93oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.15mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 30
Constants
- kV: 3700
- Rm: 0.057
- Io: 1.2
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1.2 | 37890 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 11 | 33.2 | 365 | 33690 | 130.8 | 685 | 24.16 | 83% |
| APC E 4.2x4 | 1 | 11 | 34.6 | 380 | 33450 | 126.7 | 653 | 23.03 | 82% |
