Motrolfly - 2205-1800
Specifications
- Type: Outrunner
- Weight: 31.00g (1.09oz)
- Maximum Amps: 9
Constants
- kV: 1890
- Rm: 0.2
- Io: 1.1
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1.1 | 18480 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Multiplex 5x4 | 1 | 6.9 | 4.25 | 29 | 11670 | 44.2 | 171 | 6.03 | 89% |
| Multiplex 5x4 | 1 | 7.9 | 5.1 | 40 | 13020 | 49.3 | 216 | 7.62 | 87% |
| Multiplex 5x4 | 1 | 8.9 | 6.2 | 55 | 14580 | 55.2 | 272 | 9.59 | 87% |
| Multiplex 5x4 | 1 | 9.9 | 7.2 | 71 | 15960 | 60.5 | 326 | 11.50 | 85% |
| Multiplex 5x4 | 1 | 10.9 | 8.3 | 90 | 17190 | 65.1 | 382 | 13.47 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 5.7 | 39 | 11040 | 51.2 | 174 | 6.14 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 6.7 | 52 | 12420 | 57.6 | 219 | 7.72 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 8.05 | 71 | 13650 | 63.3 | 267 | 9.42 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 9.6 | 95 | 14910 | 69.2 | 320 | 11.29 | 80% |
| Zagi Carbon 5.1x4.9 | 1 | 10.9 | 11 | 119 | 16050 | 74.5 | 365 | 12.87 | 78% |
| GWS HD 6x3 | 1 | 6.9 | 4.65 | 32 | 11490 | 32.6 | 219 | 7.72 | 88% |
| GWS HD 6x3 | 1 | 7.9 | 5.65 | 44 | 12840 | 36.5 | 277 | 9.77 | 86% |
| GWS HD 6x3 | 1 | 8.9 | 6.7 | 59 | 14160 | 40.2 | 338 | 11.92 | 84% |
| GWS HD 6x3 | 1 | 9.9 | 8 | 79 | 15540 | 44.1 | 413 | 14.57 | 83% |
| GWS HD 6x3 | 1 | 10.5 | 8.7 | 91 | 16230 | 46.1 | 456 | 16.08 | 82% |
| GWS HD 7x3.5 | 1 | 6.9 | 6 | 41 | 10950 | 36.3 | 287 | 10.12 | 84% |
| GWS HD 7x3.5 | 1 | 7.9 | 7.3 | 57 | 12150 | 40.3 | 362 | 12.77 | 81% |
| GWS HD 7x3.5 | 1 | 8.9 | 8.75 | 77 | 13320 | 44.1 | 445 | 15.70 | 79% |
| GWS HD 7x3.5 | 1 | 9.8 | 10.4 | 101 | 14550 | 48.2 | 530 | 18.70 | 79% |
| GWS HD 7x3.5 | 1 | 10.8 | 12 | 129 | 15480 | 51.3 | 620 | 21.87 | 76% |
| APC SF 7x4 | 1 | 7 | 9.6 | 67 | 9750 | 36.9 | 382 | 13.47 | 74% |
| APC SF 7x4 | 1 | 7.4 | 10.3 | 76 | 10050 | 38.1 | 409 | 14.43 | 72% |
| GWS RS 8x4.3 | 1 | 7 | 12.5 | 87 | 8400 | 34.2 | 480 | 16.93 | 63% |
