Suppo - A2212-6 Blue


Suppo - A2212-6 Blue

Specifications

  • Type: Outrunner
  • Weight: 55.00g (1.94oz)
  • Diameter: 27.60mm (1.09in)
  • Length: 27.25mm (1.07in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 28

Constants

  • kV: 2150
  • Rm: 0.1
  • Io: 2.2



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 2.2 21000

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 5x5 1 6.9 8.2 56 13080 61.9 178 6.28 88%
APC E 5x5 1 7.9 10.1 79 14700 69.6 227 8.01 87%
APC E 5x5 1 8.9 12.25 109 16320 77.3 283 9.98 85%
APC E 5x5 1 9.8 14.35 140 17790 84.2 336 11.85 84%
APC E 5x5 1 10.6 16.85 178 19140 90.6 390 13.76 84%
Zagi Carbon 5.1x4.9 1 6.8 8.1 55 13020 60.4 247 8.71 89%
Zagi Carbon 5.1x4.9 1 7.8 10.1 78 14610 67.8 317 11.18 87%
Zagi Carbon 5.1x4.9 1 8.8 12.3 108 16350 75.9 394 13.90 86%
Zagi Carbon 5.1x4.9 1 9.8 14.6 143 17760 82.4 472 16.65 84%
Zagi Carbon 5.1x4.9 1 10.7 17 181 19140 88.8 555 19.58 83%
APC E 5.5x4.5 1 6.8 9.5 64 12780 54.5 242 8.54 87%
APC E 5.5x4.5 1 7.8 11.8 92 14460 61.6 309 10.90 86%
APC E 5.5x4.5 1 8.8 14.3 125 15900 67.8 381 13.44 84%
APC E 5.5x4.5 1 9.7 16.7 161 17280 73.6 457 16.12 83%
APC E 5.5x4.5 1 10.6 19.3 204 18660 79.5 542 19.12 82%
APC E 6x4 1 6.8 9.7 65 12780 48.4 330 11.64 87%
APC E 6x4 1 7.8 12 93 14400 54.5 420 14.82 86%
APC E 6x4 1 8.8 14.4 126 15810 59.9 524 18.48 84%
APC E 6x4 1 9.7 16.95 164 17370 65.8 632 22.29 83%
APC E 6x4 1 10.7 19.8 211 18720 70.9 740 26.10 81%
APC E 6x5.5 1 6.8 13.1 89 12120 63.1 337 11.89 83%
APC E 6x5.5 1 7.8 15.75 122 13500 70.3 424 14.96 81%
APC E 6x5.5 1 8.7 18.5 160 14790 77.0 519 18.31 79%
APC E 6x5.5 1 9.7 21.8 211 16200 84.4 622 21.94 78%
APC E 6x5.5 1 10.5 24.6 258 17300 90.1 694 24.48 77%
APC E 6x5.5 1 11.3 27.5 310 18000 93.8 768 27.09 74%
Graupner CAM Speed 6x6 1 6.8 13.1 89 12180 69.2 323 11.39 83%
Graupner CAM Speed 6x6 1 7.8 15.8 123 13500 76.7 402 14.18 81%
Graupner CAM Speed 6x6 1 8.7 18.65 162 14820 84.2 495 17.46 79%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Graupner CAM Speed 6x6 1 9.7 22 213 16200 92.0 585 20.64 78%
Graupner CAM Speed 6x6 1 10.2 23.9 243 17280 98.2 636 22.43 79%
