ARC - 2215-3550
Specifications
- Type: Outrunner
- Weight: 65.00g (2.29oz)
- Diameter: 27.80mm (1.09in)
- Length: 34.75mm (1.37in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 30
Constants
- kV: 3740
- Rm: 0.055
- Io: 2.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 2.2 | 25820 |
| 8 | 2.35 | 29450 |
| 10 | 2.65 | 36800 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 10x6 | 4.75 | 6.9 | 7.7 | 53 | 5100 | 29.0 | 353 | 12.45 | 94% |
| GWS HD 10x6 | 4.75 | 7.9 | 9.2 | 72 | 5820 | 33.1 | 454 | 16.01 | 94% |
| GWS HD 10x6 | 4.75 | 8.9 | 10.85 | 96 | 6510 | 37.0 | 582 | 20.53 | 93% |
| GWS HD 10x6 | 4.75 | 9.9 | 12.6 | 124 | 7200 | 40.9 | 703 | 24.80 | 92% |
| GWS HD 10x6 | 4.75 | 10.8 | 14.45 | 156 | 7830 | 44.5 | 830 | 29.28 | 92% |
| GWS HD 11x7 | 4.75 | 6.8 | 10.65 | 72 | 4950 | 32.8 | 537 | 18.94 | 92% |
| GWS HD 11x7 | 4.75 | 7.8 | 13.1 | 102 | 5610 | 37.2 | 690 | 24.34 | 91% |
| GWS HD 11x7 | 4.75 | 8.8 | 15.6 | 137 | 6210 | 41.2 | 852 | 30.05 | 90% |
| GWS HD 11x7 | 4.75 | 9.8 | 18.5 | 181 | 6840 | 45.3 | 1022 | 36.05 | 89% |
| GWS HD 11x7 | 4.75 | 10.7 | 21.4 | 228 | 7410 | 49.1 | 1208 | 42.61 | 88% |
| GWS HD 12x6 | 4.75 | 6.9 | 11.5 | 79 | 4920 | 27.9 | 604 | 21.31 | 91% |
| GWS HD 12x6 | 4.75 | 7.8 | 14.2 | 110 | 5550 | 31.5 | 785 | 27.69 | 90% |
| GWS HD 12x6 | 4.75 | 8.8 | 17 | 149 | 6150 | 34.9 | 970 | 34.22 | 89% |
| GWS HD 12x6 | 4.75 | 9.7 | 19.8 | 192 | 6750 | 38.4 | 1144 | 40.35 | 88% |
| GWS HD 12x6 | 4.75 | 10.7 | 23.4 | 250 | 7290 | 41.4 | 1370 | 48.33 | 87% |
| APC E 13x6.5 | 4.75 | 7.4 | 17.45 | 129 | 5130 | 31.6 | 928 | 32.73 | 88% |
| APC E 13x6.5 | 4.75 | 10.7 | 32 | 342 | 6900 | 42.5 | 1753 | 61.84 | 82% |
| APC E 13x6.5 | 4.75 | 11.2 | 34.8 | 389 | 7170 | 44.1 | 1902 | 67.09 | 81% |
