Suppo - A2217K/9T
Specifications
- Type: Outrunner
- Weight: 70.00g (2.47oz)
- Diameter: 27.60mm (1.09in)
- Length: 33.60mm (1.32in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 16
Constants
- kV: 1035
- Rm: 0.18
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 11.9 | 1.05 | 12838 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 7 | 3.5 | 24 | 6690 | 25.3 | 226 | 7.97 | 92% |
| GWS HD 8x4 | 1 | 7.9 | 4.25 | 33 | 7500 | 28.4 | 283 | 9.98 | 92% |
| GWS HD 8x4 | 1 | 8.9 | 5.1 | 45 | 8340 | 31.6 | 354 | 12.49 | 91% |
| GWS HD 8x4 | 1 | 9.9 | 6.05 | 59 | 9180 | 34.8 | 436 | 15.38 | 90% |
| GWS HD 8x4 | 1 | 10.9 | 7.1 | 77 | 9960 | 37.7 | 519 | 18.31 | 88% |
| GWS HD 9x5 | 1 | 6.9 | 6 | 41 | 6240 | 29.6 | 374 | 13.19 | 87% |
| GWS HD 9x5 | 1 | 7.9 | 7.35 | 58 | 6990 | 33.1 | 471 | 16.61 | 85% |
| GWS HD 9x5 | 1 | 8.9 | 8.8 | 78 | 7680 | 36.4 | 574 | 20.25 | 83% |
| GWS HD 9x5 | 1 | 9.8 | 10.3 | 100 | 8370 | 39.6 | 688 | 24.27 | 83% |
| GWS HD 9x5 | 1 | 10.9 | 11.95 | 130 | 9000 | 42.6 | 808 | 28.50 | 80% |
| APC SF 10x4.7 | 1 | 6.9 | 10.1 | 69 | 5520 | 24.6 | 552 | 19.47 | 77% |
| APC SF 10x4.7 | 1 | 7.9 | 12.4 | 97 | 6060 | 27.0 | 679 | 23.95 | 74% |
| APC SF 10x4.7 | 1 | 8.8 | 14.7 | 129 | 6570 | 29.2 | 809 | 28.54 | 72% |
| APC SF 10x4.7 | 1 | 9.8 | 17.05 | 167 | 7050 | 31.4 | 936 | 33.02 | 70% |
| APC SF 10x4.7 | 1 | 10.8 | 19.5 | 210 | 7470 | 33.2 | 1066 | 37.60 | 67% |
| GWS HD 10x6 | 1 | 6.9 | 7.8 | 53 | 5880 | 33.4 | 461 | 16.26 | 82% |
| GWS HD 10x6 | 1 | 7.9 | 9.5 | 75 | 6570 | 37.3 | 572 | 20.18 | 80% |
| GWS HD 10x6 | 1 | 8.9 | 11.3 | 100 | 7170 | 40.7 | 696 | 24.55 | 78% |
| GWS HD 10x6 | 1 | 9.9 | 13.25 | 131 | 7800 | 44.3 | 815 | 28.75 | 76% |
| GWS HD 10x6 | 1 | 10.8 | 15.1 | 163 | 8340 | 47.4 | 938 | 33.09 | 75% |
| GWS HD 10x8 | 1 | 6.9 | 12 | 82 | 5190 | 39.3 | 472 | 16.65 | 73% |
| GWS HD 10x8 | 1 | 7.8 | 14.35 | 111 | 5700 | 43.2 | 565 | 19.93 | 71% |
| GWS HD 10x8 | 1 | 8.8 | 16.9 | 148 | 6180 | 46.8 | 671 | 23.67 | 68% |
| GWS HD 10x8 | 1 | 9.7 | 19.2 | 186 | 6600 | 50.0 | 759 | 26.77 | 66% |
| GWS HD 10x8 | 1 | 10.7 | 21.7 | 232 | 6960 | 52.7 | 852 | 30.05 | 63% |
