Grayson - Mega Jet 23



Specifications

  • Type: Outrunner
  • Weight: 54.00g (1.90oz)
  • Maximum Amps: 25

Constants

  • kV: 2655
  • Rm: 0.09
  • Io: 1.75



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 1.75 26130

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 4.1x4.1 1 6.9 8.3 57 16260 63.1 217 7.65 89%
APC E 4.1x4.1 1 7.8 10.2 79 18150 70.5 274 9.67 88%
APC E 4.1x4.1 1 8.9 12.5 111 20160 78.3 340 11.99 85%
APC E 4.1x4.1 1 9.8 14.8 145 22860 88.8 410 14.46 88%
APC E 4.1x4.1 1 10.8 17.2 185 24150 93.8 472 16.65 84%
