Suppo - A2204-14
Specifications
- Type: Outrunner
- Weight: 19.00g (0.67oz)
- Diameter: 27.60mm (1.09in)
- Length: 18.80mm (0.74in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 7.5
Constants
- kV: 1570
- Rm: 0.44
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.65 | 14850 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 6x5.5 | 1 | 7 | 4.4 | 30 | 8010 | 41.7 | 133 | 4.69 | 73% |
| APC E 6x5.5 | 1 | 7.4 | 4.8 | 35 | 8400 | 43.8 | 147 | 5.19 | 72% |
| APC E 6x5.5 | 1 | 7.9 | 5.2 | 41 | 8880 | 46.2 | 166 | 5.86 | 72% |
| APC E 6x5.5 | 1 | 8.9 | 6.1 | 54 | 9660 | 50.3 | 202 | 7.13 | 69% |
| APC E 6x5.5 | 1 | 9.9 | 7 | 69 | 10470 | 54.5 | 239 | 8.43 | 67% |
| APC E 6x5.5 | 1 | 10.9 | 7.9 | 86 | 11220 | 58.4 | 280 | 9.88 | 66% |
| APC E 6x5.5 | 1 | 11.1 | 8.05 | 89 | 11430 | 59.5 | 286 | 10.09 | 66% |
| GWS HD 7x3.5 | 1 | 7 | 3.1 | 21 | 8880 | 29.4 | 157 | 5.54 | 81% |
| GWS HD 7x3.5 | 1 | 7.4 | 3.3 | 24 | 9300 | 30.8 | 182 | 6.42 | 80% |
| GWS HD 7x3.5 | 1 | 7.9 | 3.75 | 29 | 9900 | 32.8 | 204 | 7.20 | 80% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.4 | 39 | 10890 | 36.1 | 251 | 8.85 | 78% |
| GWS HD 7x3.5 | 1 | 9.9 | 5.1 | 50 | 11790 | 39.1 | 297 | 10.48 | 76% |
| GWS HD 7x3.5 | 1 | 10.9 | 5.85 | 63 | 12600 | 41.8 | 348 | 12.28 | 74% |
| GWS HD 7x3.5 | 1 | 11.1 | 6 | 66 | 12750 | 42.3 | 365 | 12.87 | 73% |
| APC SF 7x4 | 1 | 7 | 4.9 | 34 | 7680 | 29.1 | 232 | 8.18 | 70% |
| APC SF 7x4 | 1 | 7.4 | 5.4 | 39 | 8010 | 30.3 | 257 | 9.07 | 69% |
| APC SF 7x4 | 1 | 7.9 | 5.9 | 46 | 8430 | 31.9 | 285 | 10.05 | 68% |
| APC SF 7x4 | 1 | 8.9 | 6.95 | 61 | 9090 | 34.4 | 334 | 11.78 | 65% |
| APC SF 7x4 | 1 | 9.9 | 8.1 | 80 | 9690 | 36.7 | 388 | 13.69 | 62% |
| APC SF 7x4 | 1 | 10.9 | 9.2 | 100 | 10170 | 38.5 | 438 | 15.45 | 59% |
| APC SF 7x4 | 1 | 11.1 | 9.5 | 105 | 10290 | 39.0 | 450 | 15.87 | 59% |
| APC E 7x5 | 1 | 6.9 | 5.65 | 38 | 7230 | 34.2 | 230 | 8.11 | 67% |
| APC E 7x5 | 1 | 6.9 | 6.1 | 42 | 7890 | 37.4 | 271 | 9.56 | 73% |
| APC E 7x5 | 1 | 7.9 | 7.3 | 57 | 8700 | 41.2 | 335 | 11.82 | 70% |
| APC E 7x5 | 1 | 7.9 | 6.7 | 52 | 7920 | 37.5 | 277 | 9.77 | 64% |
| APC E 7x5 | 1 | 8.9 | 8.7 | 77 | 9510 | 45.0 | 413 | 14.57 | 68% |
| APC E 7x5 | 1 | 8.9 | 7.75 | 68 | 8580 | 40.6 | 331 | 11.68 | 61% |
| APC E 7x5 | 1 | 9.9 | 10.1 | 99 | 10290 | 48.7 | 481 | 16.97 | 66% |
| APC E 7x5 | 1 | 9.9 | 8.8 | 87 | 9180 | 43.5 | 377 | 13.30 | 59% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 7x5 | 1 | 10.8 | 11.6 | 125 | 11010 | 52.1 | 559 | 19.72 | 65% |
| APC E 7x5 | 1 | 10.9 | 10 | 109 | 9570 | 45.3 | 428 | 15.10 | 56% |
| GWS HD 8x4 | 1 | 6.9 | 5.4 | 37 | 7380 | 27.9 | 281 | 9.91 | 68% |
| GWS HD 8x4 | 1 | 7.4 | 5.9 | 43 | 7740 | 29.3 | 310 | 10.93 | 67% |
