E-max - BL 2205/22
Specifications
- Type: Outrunner
- Weight: 29.00g (1.02oz)
- Diameter: 28.00mm (1.10in)
- Length: 22.00mm (0.87in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 11
Constants
- kV: 1940
- Rm: 0.418
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 6.03 | 0.62 | 11340 |
| 8.03 | 0.72 | 15090 |
| 10.09 | 0.85 | 18900 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 6x4 | 1 | 6.9 | 5 | 34 | 9960 | 37.7 | 195 | 6.88 | 74% |
| APC E 6x4 | 1 | 7.9 | 6.1 | 48 | 11040 | 41.8 | 242 | 8.54 | 72% |
| APC E 6x4 | 1 | 8.9 | 7.2 | 64 | 12000 | 45.5 | 291 | 10.26 | 70% |
| APC E 6x4 | 1 | 9.9 | 8.4 | 83 | 12870 | 48.8 | 343 | 12.10 | 67% |
| APC E 6x4 | 1 | 10.9 | 9.6 | 104 | 13710 | 51.9 | 390 | 13.76 | 65% |
| GWS HD 7x3.5 | 1 | 6.9 | 4.9 | 33 | 9990 | 33.1 | 237 | 8.36 | 75% |
| GWS HD 7x3.5 | 1 | 7.9 | 5.9 | 46 | 11010 | 36.5 | 296 | 10.44 | 72% |
| GWS HD 7x3.5 | 1 | 8.9 | 7.05 | 62 | 12000 | 39.8 | 360 | 12.70 | 70% |
| GWS HD 7x3.5 | 1 | 9.9 | 8.15 | 80 | 12900 | 42.8 | 418 | 14.74 | 67% |
| GWS HD 7x3.5 | 1 | 10.9 | 9.3 | 101 | 13620 | 45.1 | 475 | 16.76 | 64% |
| APC SF 8x3.8 | 1 | 6.9 | 9.5 | 65 | 6690 | 24.1 | 333 | 11.75 | 50% |
| APC SF 8x3.8 | 1 | 7.4 | 9.8 | 72 | 6810 | 24.5 | 345 | 12.17 | 47% |
| GWS HD 8x4 | 1 | 6.9 | 8.2 | 56 | 7770 | 29.4 | 330 | 11.64 | 58% |
