GPS - C28-26-C
Specifications
- Type: Outrunner
- Weight: 46.00g (1.62oz)
- Diameter: 27.80mm (1.09in)
- Length: 27.00mm (1.06in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 12
Constants
- kV: 1120
- Rm: 0.32
- Io: 0.75
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.75 | 10920 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 6.9 | 2.05 | 14 | 7200 | 23.9 | 121 | 4.27 | 93% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.5 | 19 | 8160 | 27.1 | 159 | 5.61 | 92% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.95 | 26 | 9060 | 30.0 | 201 | 7.09 | 91% |
| GWS HD 7x3.5 | 1 | 9.9 | 3.4 | 33 | 9960 | 33.0 | 247 | 8.71 | 90% |
| GWS HD 7x3.5 | 1 | 10.9 | 3.95 | 43 | 10800 | 35.8 | 296 | 10.44 | 88% |
| GWS HD 8x4 | 1 | 6.9 | 3.8 | 26 | 6660 | 25.2 | 242 | 8.54 | 86% |
| GWS HD 8x4 | 1 | 7.9 | 4.55 | 35 | 7470 | 28.3 | 303 | 10.69 | 84% |
| GWS HD 8x4 | 1 | 8.9 | 5.4 | 48 | 8220 | 31.1 | 371 | 13.09 | 82% |
| GWS HD 8x4 | 1 | 9.9 | 6.25 | 61 | 8880 | 33.6 | 438 | 15.45 | 80% |
| GWS HD 8x4 | 1 | 10.9 | 7.2 | 78 | 9570 | 36.2 | 516 | 18.20 | 78% |
| GWS HD 9x5 | 1 | 6.9 | 5.95 | 41 | 5970 | 28.3 | 360 | 12.70 | 77% |
| GWS HD 9x5 | 1 | 7.9 | 7.15 | 56 | 6600 | 31.2 | 447 | 15.77 | 75% |
| GWS HD 9x5 | 1 | 8.9 | 8.25 | 73 | 7170 | 34.0 | 523 | 18.45 | 72% |
| GWS HD 9x5 | 1 | 9.9 | 9.55 | 94 | 7710 | 36.5 | 618 | 21.80 | 70% |
| GWS HD 10x6 | 1 | 6.9 | 7.6 | 52 | 5430 | 30.9 | 427 | 15.06 | 70% |
| GWS HD 10x6 | 1 | 7.9 | 8.9 | 70 | 5910 | 33.6 | 503 | 17.74 | 67% |
| GWS HD 10x6 | 1 | 8.9 | 10.3 | 91 | 6390 | 36.3 | 591 | 20.85 | 64% |
| GWS HD 10x6 | 1 | 9.9 | 11.7 | 115 | 6870 | 39.0 | 677 | 23.88 | 62% |
| GWS HD 10x6 | 1 | 10.9 | 13.1 | 142 | 7170 | 40.7 | 750 | 26.46 | 59% |
