Motrolfly - 2210-1400
Specifications
- Type: Outrunner
- Weight: 45.00g (1.59oz)
- Maximum Amps: 14
Constants
- kV: 1330
- Rm: 0.18
- Io: 1
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1 | 13080 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Graupner Speed 6.5x6.5 | 1 | 6.9 | 5.65 | 38 | 8130 | 50.0 | 185 | 6.53 | 89% |
| Graupner Speed 6.5x6.5 | 1 | 7.9 | 6.9 | 54 | 9120 | 56.1 | 232 | 8.18 | 87% |
| Graupner Speed 6.5x6.5 | 1 | 8.9 | 8.35 | 74 | 10110 | 62.2 | 285 | 10.05 | 85% |
| Graupner Speed 6.5x6.5 | 1 | 9.9 | 9.75 | 96 | 10800 | 66.5 | 340 | 11.99 | 82% |
| Graupner Speed 6.5x6.5 | 1 | 10.8 | 11.2 | 120 | 11880 | 73.1 | 397 | 14.00 | 83% |
| GWS HD 7x3.5 | 1 | 7 | 3.2 | 22 | 8700 | 28.8 | 172 | 6.07 | 93% |
| GWS HD 7x3.5 | 1 | 7.9 | 3.9 | 30 | 9960 | 33.0 | 230 | 8.11 | 95% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.65 | 41 | 10920 | 36.2 | 287 | 10.12 | 92% |
| GWS HD 7x3.5 | 1 | 9.9 | 5.5 | 54 | 12000 | 39.8 | 357 | 12.59 | 91% |
| GWS HD 7x3.5 | 1 | 10.9 | 6.4 | 69 | 13080 | 43.4 | 427 | 15.06 | 90% |
| APC SF 7x4 | 1 | 6.9 | 5.25 | 36 | 8190 | 31.0 | 269 | 9.49 | 89% |
| APC SF 7x4 | 1 | 7.9 | 6.5 | 51 | 9300 | 35.2 | 349 | 12.31 | 89% |
| APC SF 7x4 | 1 | 8.9 | 7.85 | 69 | 10170 | 38.5 | 427 | 15.06 | 86% |
| APC SF 7x4 | 1 | 9.9 | 9.45 | 93 | 11100 | 42.0 | 519 | 18.31 | 84% |
| APC SF 7x4 | 1 | 10.8 | 11.1 | 119 | 11910 | 45.1 | 610 | 21.52 | 83% |
| APC E 7x5 | 1 | 6.9 | 6.3 | 43 | 8010 | 37.9 | 288 | 10.16 | 87% |
| APC E 7x5 | 1 | 7.9 | 7.7 | 60 | 8940 | 42.3 | 369 | 13.02 | 85% |
| APC E 7x5 | 1 | 8.9 | 9.25 | 82 | 9900 | 46.9 | 452 | 15.94 | 84% |
| APC E 7x5 | 1 | 9.9 | 10.9 | 107 | 10740 | 50.9 | 542 | 19.12 | 82% |
| APC E 7x5 | 1 | 10.9 | 12.5 | 136 | 11520 | 54.5 | 626 | 22.08 | 79% |
| APC Sport 7x7 | 1 | 6.9 | 7 | 48 | 7830 | 51.9 | 264 | 9.31 | 85% |
| APC Sport 7x7 | 1 | 7.9 | 8.5 | 67 | 8760 | 58.1 | 334 | 11.78 | 83% |
| APC Sport 7x7 | 1 | 8.9 | 10.2 | 90 | 9630 | 63.8 | 408 | 14.39 | 81% |
| APC Sport 7x7 | 1 | 9.8 | 11.85 | 116 | 10470 | 69.4 | 483 | 17.04 | 80% |
| APC Sport 7x7 | 1 | 10.8 | 13.5 | 145 | 11280 | 74.8 | 556 | 19.61 | 79% |
| GWS HD 8x4 | 1 | 6.9 | 6 | 41 | 8040 | 30.4 | 339 | 11.96 | 88% |
| GWS HD 8x4 | 1 | 7.9 | 7.4 | 58 | 8970 | 34.0 | 431 | 15.20 | 85% |
| GWS HD 8x4 | 1 | 8.9 | 8.95 | 79 | 9930 | 37.6 | 527 | 18.59 | 84% |
| GWS HD 8x4 | 1 | 9.9 | 10.6 | 104 | 10800 | 40.9 | 630 | 22.22 | 82% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 8x4 | 1 | 10.9 | 12.25 | 133 | 11610 | 44.0 | 738 | 26.03 | 80% |
| APC E 8x4 | 1 | 6.9 | 7.6 | 52 | 7740 | 29.3 | 385 | 13.58 | 84% |
| APC E 8x4 | 1 | 7.9 | 9.3 | 73 | 8580 | 32.5 | 484 | 17.07 | 82% |
| APC E 8x4 | 1 | 8.9 | 11.1 | 98 | 9390 | 35.6 | 583 | 20.56 | 79% |
| APC E 8x4 | 1 | 9.9 | 12.9 | 127 | 10140 | 38.4 | 693 | 24.44 | 77% |
| APC E 8x4 | 1 | 10.8 | 15 | 162 | 10890 | 41.2 | 805 | 28.40 | 76% |
| GWS HD 8x6 | 1 | 6.8 | 9.55 | 64 | 7260 | 41.2 | 385 | 13.58 | 80% |
| GWS HD 8x6 | 1 | 7.9 | 11.7 | 92 | 8040 | 45.7 | 478 | 16.86 | 77% |
| GWS HD 8x6 | 1 | 8.9 | 13.85 | 123 | 8760 | 49.8 | 562 | 19.82 | 74% |
| GWS HD 8x6 | 1 | 9.7 | 16.05 | 155 | 9360 | 53.2 | 651 | 22.96 | 73% |
| APC E 8x6 | 1 | 6.8 | 10.5 | 71 | 7020 | 39.9 | 380 | 13.40 | 78% |
| APC E 8x6 | 1 | 7.8 | 12.7 | 99 | 7710 | 43.8 | 460 | 16.23 | 74% |
| APC E 8x6 | 1 | 8.8 | 15.2 | 133 | 8370 | 47.6 | 546 | 19.26 | 72% |
| APC E 8x6 | 1 | 9.7 | 17.8 | 172 | 8910 | 50.6 | 630 | 22.22 | 69% |
| APC E 8x6 | 1 | 10.7 | 20 | 214 | 9360 | 53.2 | 695 | 24.52 | 66% |
