Suppo - A2208/17



Specifications

  • Type: Outrunner
  • Weight: 39.00g (1.38oz)
  • Diameter: 27.60mm (1.09in)
  • Length: 22.60mm (0.89in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 8

Constants

  • kV: 1280
  • Rm: 0.444
  • Io: 0.55



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.45 8700
8 0.5 10150
10 0.55 12500

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 6x5.5 1 10.9 5.8 63 10530 54.8 251 8.85 75%
APC E 6x5.5 1 14 7.85 109 12840 66.9 374 13.19 72%
GWS HD 8x4 1 6.9 3.9 26 6870 26.0 244 8.61 78%
GWS HD 8x4 1 7.9 4.7 37 7620 28.9 300 10.58 75%
GWS HD 8x4 1 8.9 5.5 48 8370 31.7 364 12.84 73%
GWS HD 8x4 1 9.9 6.4 63 9060 34.3 430 15.17 71%
GWS HD 8x4 1 10.9 7.3 79 9720 36.8 494 17.43 70%
GWS HD 9x5 1 6.9 6 41 5940 28.1 339 11.96 67%
GWS HD 9x5 1 7.9 7.2 56 6510 30.8 415 14.64 64%
GWS HD 9x5 1 8.9 8.4 74 7020 33.2 484 17.07 62%
GWS HD 9x5 1 9.9 9.5 94 7470 35.4 556 19.61 59%
APC E 10x5 1 6.9 7.35 50 5310 25.1 371 13.09 60%
APC E 10x5 1 7.4 7.95 58 5550 26.3 400 14.11 59%
