Grayson - Mega Jet 25



Specifications

  • Type: Outrunner
  • Weight: 53.00g (1.87oz)
  • Maximum Amps: 25

Constants

  • kV: 2930
  • Rm: 0.1
  • Io: 1.95



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 1.95 28710

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 4.1x4.1 1 6.9 8.85 61 17910 69.5 185 6.53 89%
APC E 4.1x4.1 1 7.9 10.4 82 20220 78.5 237 8.36 87%
APC E 4.1x4.1 1 8.8 12.55 110 22350 86.8 293 10.34 87%
APC E 4.1x4.1 1 9.8 15 147 24600 95.5 352 12.42 86%
APC E 4.1x4.1 1 10.8 17.5 189 26640 103.4 410 14.46 84%
APC E 4.5x4.1 1 6.9 11.1 76 17310 67.2 242 8.54 86%
APC E 4.5x4.1 1 7.8 13.2 102 19320 75.0 307 10.83 85%
APC E 4.5x4.1 1 8.8 15.6 137 21420 83.2 382 13.47 83%
APC E 4.5x4.1 1 9.7 18.5 179 23190 90.0 454 16.01 82%
APC E 4.5x4.1 1 10.7 21.5 230 24990 97.0 511 18.02 80%
APC E 4.7x4.25 1 6.8 11.7 79 17010 68.5 253 8.92 85%
APC E 4.7x4.25 1 7.8 14.85 115 18750 75.5 310 10.93 82%
APC E 4.7x4.25 1 8.8 17.45 153 20700 83.3 382 13.47 80%
APC E 4.7x4.25 1 9.8 20.4 199 22470 90.4 453 15.98 78%
APC E 4.7x4.25 1 10.7 23.7 253 24060 96.8 515 18.17 77%
Graupner CAM Speed 4.7x4.7 1 6.8 12.9 87 16560 73.7 266 9.38 83%
Graupner CAM Speed 4.7x4.7 1 7.8 15.9 124 18390 81.8 331 11.68 80%
Graupner CAM Speed 4.7x4.7 1 8.7 19.5 169 20100 89.5 396 13.97 79%
Graupner CAM Speed 4.7x4.7 1 10.7 26.1 279 23220 103.3 530 18.70 74%
APC E 5x5 1 7.6 17.9 136 17220 81.5 311 10.97 77%
Zagi Carbon 5.1x4.9 1 11.2 30.4 340 22680 105.2 750 26.46 69%
