HXT - 3530-10-1000
Specifications
- Type: Outrunner
- Weight: 77.00g (2.72oz)
- Maximum Amps: 20
Constants
- kV: 1085
- Rm: 0.18
- Io: 1
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1 | 10650 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.9 | 6.7 | 46 | 6420 | 30.4 | 397 | 14.00 | 86% |
| GWS HD 9x5 | 1 | 7.9 | 8.2 | 64 | 7140 | 33.8 | 504 | 17.78 | 83% |
| GWS HD 9x5 | 1 | 8.9 | 9.8 | 87 | 7860 | 37.2 | 614 | 21.66 | 81% |
| GWS HD 9x5 | 1 | 9.8 | 11.5 | 112 | 8550 | 40.5 | 725 | 25.57 | 80% |
| GWS HD 9x5 | 1 | 10.8 | 13.35 | 144 | 9210 | 43.6 | 854 | 30.12 | 79% |
| APC E 10x5 | 1 | 6.9 | 8.7 | 60 | 6060 | 28.7 | 485 | 17.11 | 81% |
| APC E 10x5 | 1 | 7.9 | 10.55 | 83 | 6690 | 31.7 | 605 | 21.34 | 78% |
| APC E 10x5 | 1 | 8.8 | 12.6 | 110 | 7320 | 34.7 | 730 | 25.75 | 77% |
| APC E 10x5 | 1 | 9.8 | 14.8 | 145 | 7950 | 37.6 | 866 | 30.55 | 75% |
| APC E 10x5 | 1 | 10.8 | 16.85 | 181 | 8490 | 40.2 | 979 | 34.53 | 72% |
| GWS HD 10x6 | 1 | 6.9 | 8.7 | 60 | 6030 | 34.3 | 491 | 17.32 | 81% |
| GWS HD 10x6 | 1 | 7.9 | 10.55 | 83 | 6660 | 37.8 | 606 | 21.38 | 78% |
| GWS HD 10x6 | 1 | 8.8 | 12.5 | 110 | 7350 | 41.8 | 726 | 25.61 | 77% |
| GWS HD 10x6 | 1 | 9.8 | 14.7 | 144 | 7950 | 45.2 | 860 | 30.34 | 75% |
| GWS HD 10x6 | 1 | 10.8 | 16.8 | 181 | 8520 | 48.4 | 975 | 34.39 | 73% |
| APC E 10x7 | 1 | 6.9 | 11.3 | 77 | 5580 | 37.0 | 461 | 16.26 | 75% |
| APC E 10x7 | 1 | 7.8 | 13.5 | 105 | 6150 | 40.8 | 568 | 20.04 | 73% |
| APC E 10x7 | 1 | 8.8 | 15.5 | 136 | 6810 | 45.1 | 726 | 25.61 | 71% |
| APC E 10x7 | 1 | 9.8 | 17.75 | 173 | 7290 | 48.3 | 830 | 29.28 | 69% |
| APC E 10x7 | 1 | 10.7 | 19.3 | 206 | 7710 | 51.1 | 961 | 33.90 | 66% |
| APC E 11x5.5 | 1 | 6.9 | 10.85 | 74 | 5670 | 29.5 | 595 | 20.99 | 76% |
| APC E 11x5.5 | 1 | 7.8 | 13.25 | 103 | 6270 | 32.7 | 737 | 26.00 | 74% |
| APC E 11x5.5 | 1 | 8.8 | 15.7 | 138 | 6810 | 35.5 | 875 | 30.86 | 71% |
| APC E 11x5.5 | 1 | 9.8 | 18 | 176 | 7200 | 37.5 | 990 | 34.92 | 68% |
| APC E 11x5.5 | 1 | 10.7 | 20.5 | 219 | 7620 | 39.7 | 1140 | 40.21 | 66% |
| GWS HD 11x7 | 1 | 6.9 | 12.45 | 85 | 5400 | 35.8 | 645 | 22.75 | 72% |
| GWS HD 11x7 | 1 | 7.8 | 14.9 | 116 | 5910 | 39.2 | 776 | 27.37 | 70% |
| GWS HD 11x7 | 1 | 8.8 | 17.5 | 154 | 6390 | 42.4 | 918 | 32.38 | 67% |
| GWS HD 11x7 | 1 | 9.8 | 20 | 196 | 6840 | 45.3 | 1031 | 36.37 | 64% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 1 | 10.7 | 22.4 | 239 | 7200 | 47.7 | 1171 | 41.31 | 62% |
