GPS - HXT C2226-25
Specifications
- Type: Outrunner
- Weight: 25.00g (0.88oz)
- Maximum Amps: 10
Constants
- kV: 1610
- Rm: 0.63
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.5 | 10920 |
| 8 | 0.6 | 12270 |
| 10 | 0.65 | 15090 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 5x3 | 1 | 7 | 1.6 | 11 | 9720 | 27.6 | 81 | 2.86 | 86% |
| GWS HD 5x3 | 1 | 7.4 | 1.7 | 12 | 10230 | 29.1 | 90 | 3.17 | 86% |
| GWS HD 5x3 | 1 | 8 | 1.9 | 15 | 10950 | 31.1 | 103 | 3.63 | 85% |
| GWS HD 5x3 | 1 | 9 | 2.2 | 19 | 12120 | 34.4 | 126 | 4.44 | 84% |
| GWS HD 5x3 | 1 | 10 | 2.55 | 25 | 13290 | 37.8 | 153 | 5.40 | 83% |
| GWS HD 5x3 | 1 | 10.9 | 2.85 | 31 | 14340 | 40.7 | 178 | 6.28 | 82% |
| Graupner CAM 5x4 | 1 | 7 | 3.25 | 22 | 8310 | 31.5 | 125 | 4.41 | 74% |
| Graupner CAM 5x4 | 1 | 7.4 | 3.5 | 25 | 8610 | 32.6 | 136 | 4.80 | 72% |
| Graupner CAM 5x4 | 1 | 7.9 | 3.9 | 30 | 9120 | 34.5 | 153 | 5.40 | 72% |
| Graupner CAM 5x4 | 1 | 8.9 | 4.5 | 40 | 9900 | 37.5 | 181 | 6.38 | 69% |
| Graupner CAM 5x4 | 1 | 9.9 | 5.1 | 50 | 10680 | 40.5 | 211 | 7.44 | 67% |
| Graupner CAM 5x4 | 1 | 10.9 | 5.75 | 62 | 11310 | 42.8 | 243 | 8.57 | 64% |
| GWS HD 5x4.3 | 1 | 7 | 2.6 | 18 | 8790 | 35.8 | 96 | 3.39 | 78% |
| GWS HD 5x4.3 | 1 | 7.4 | 2.9 | 21 | 9210 | 37.5 | 104 | 3.67 | 77% |
| GWS HD 5x4.3 | 1 | 7.9 | 3.2 | 25 | 9720 | 39.6 | 115 | 4.06 | 76% |
| GWS HD 5x4.3 | 1 | 8.9 | 3.8 | 33 | 10530 | 42.9 | 132 | 4.66 | 73% |
| GWS HD 5x4.3 | 1 | 9.9 | 4.6 | 45 | 11250 | 45.8 | 145 | 5.11 | 71% |
| GWS HD 5x4.3 | 1 | 10.9 | 5.2 | 56 | 12000 | 48.9 | 162 | 5.71 | 68% |
| GWS HD 6x3 | 1 | 7 | 2.2 | 15 | 9180 | 26.1 | 125 | 4.41 | 81% |
| GWS HD 6x3 | 1 | 7.4 | 2.4 | 17 | 9660 | 27.4 | 140 | 4.94 | 81% |
| GWS HD 6x3 | 1 | 8 | 2.65 | 21 | 10230 | 29.1 | 157 | 5.54 | 79% |
| GWS HD 6x3 | 1 | 8.9 | 3.1 | 27 | 11190 | 31.8 | 193 | 6.81 | 78% |
| GWS HD 6x3 | 1 | 9.9 | 3.6 | 35 | 12150 | 34.5 | 229 | 8.08 | 76% |
| GWS HD 6x3 | 1 | 10.9 | 4.1 | 44 | 13110 | 37.2 | 269 | 9.49 | 75% |
| GWS RS 6x5 | 1 | 6.9 | 4.1 | 28 | 7440 | 35.2 | 156 | 5.50 | 67% |
| GWS RS 6x5 | 1 | 7.4 | 4.5 | 33 | 7770 | 36.8 | 170 | 6.00 | 65% |
| GWS RS 6x5 | 1 | 7.9 | 4.9 | 38 | 8100 | 38.4 | 184 | 6.49 | 64% |
| GWS RS 6x5 | 1 | 8.9 | 5.65 | 50 | 8640 | 40.9 | 214 | 7.55 | 60% |
| GWS RS 6x5 | 1 | 9.9 | 6.5 | 64 | 9180 | 43.5 | 245 | 8.64 | 58% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 6x5 | 1 | 10.9 | 7.3 | 79 | 9480 | 44.9 | 265 | 9.35 | 54% |
| GWS HD 7x3.5 | 1 | 7 | 2.95 | 20 | 8580 | 28.4 | 156 | 5.50 | 76% |
| GWS HD 7x3.5 | 1 | 7.4 | 3.2 | 23 | 8940 | 29.6 | 173 | 6.10 | 75% |
| GWS HD 7x3.5 | 1 | 7.9 | 3.5 | 27 | 9450 | 31.3 | 194 | 6.84 | 74% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.1 | 36 | 10260 | 34.0 | 233 | 8.22 | 72% |
| GWS HD 7x3.5 | 1 | 9.9 | 4.7 | 46 | 11070 | 36.7 | 280 | 9.88 | 69% |
| GWS HD 7x3.5 | 1 | 10.9 | 5.35 | 58 | 11790 | 39.1 | 323 | 11.39 | 67% |
| APC SF 7x4 | 1 | 6.9 | 4.4 | 30 | 7290 | 27.6 | 204 | 7.20 | 66% |
| APC SF 7x4 | 1 | 7.4 | 4.75 | 35 | 7530 | 28.5 | 212 | 7.48 | 63% |
| APC SF 7x4 | 1 | 7.9 | 5.1 | 40 | 7770 | 29.4 | 236 | 8.32 | 61% |
| APC SF 7x4 | 1 | 8.9 | 5.9 | 52 | 8310 | 31.5 | 270 | 9.52 | 58% |
| APC SF 7x4 | 1 | 9.9 | 6.75 | 66 | 8670 | 32.8 | 305 | 10.76 | 54% |
| APC SF 7x4 | 1 | 10.9 | 7.4 | 80 | 9090 | 34.4 | 338 | 11.92 | 52% |
| APC SF 7x6 | 1 | 6.9 | 5.8 | 40 | 6030 | 34.3 | 216 | 7.62 | 54% |
| APC SF 7x6 | 1 | 7.4 | 6.1 | 45 | 6210 | 35.3 | 225 | 7.94 | 52% |
| APC SF 7x6 | 1 | 7.9 | 6.5 | 51 | 6390 | 36.3 | 239 | 8.43 | 50% |
| APC SF 7x6 | 1 | 8.9 | 7.35 | 65 | 6690 | 38.0 | 267 | 9.42 | 47% |
| APC SF 7x6 | 1 | 9.9 | 8.05 | 79 | 6960 | 39.5 | 291 | 10.26 | 44% |
| APC SF 7x6 | 1 | 10.9 | 8.7 | 94 | 7260 | 41.2 | 317 | 11.18 | 41% |
| GWS RS 8x3.8 | 1 | 6.9 | 5.7 | 39 | 5970 | 21.5 | 242 | 8.54 | 54% |
