Mega - RCn 400/7/12
Specifications
- Type: Outrunner
- Weight: 39.00g (1.38oz)
- Diameter: 28.00mm (1.10in)
- Length: 26.25mm (1.03in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 10
Constants
- kV: 1080
- Rm: 0.44
- Io: 0.4
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.35 | 7460 |
| 8 | 0.35 | 8470 |
| 10 | 0.4 | 10570 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Aeronaut 6.5x4 | 1 | 10.9 | 3.8 | 41 | 9330 | 35.3 | 261 | 9.21 | 79% |
| Aeronaut 6.5x4 | 1 | 14.6 | 6 | 87 | 12960 | 49.1 | 441 | 15.56 | 82% |
| MAS 3-blade 7x4 | 1 | 10.7 | 5.8 | 62 | 8960 | 33.9 | 318 | 11.22 | 78% |
| MAS 3-blade 7x4 | 1 | 14.6 | 8.8 | 128 | 11240 | 42.6 | 532 | 18.77 | 71% |
| APC E 7x5 | 1 | 6.9 | 2.95 | 20 | 6180 | 29.3 | 151 | 5.33 | 83% |
| APC E 7x5 | 1 | 7.9 | 3.6 | 28 | 6990 | 33.1 | 195 | 6.88 | 82% |
| APC E 7x5 | 1 | 8.9 | 4.2 | 37 | 7710 | 36.5 | 236 | 8.32 | 80% |
| APC E 7x5 | 1 | 9.8 | 4.9 | 48 | 8370 | 39.6 | 284 | 10.02 | 79% |
| APC E 7x5 | 1 | 10.8 | 5.7 | 61 | 9030 | 42.8 | 339 | 11.96 | 77% |
| APC E 7x5 | 1 | 11.8 | 6.5 | 76 | 9630 | 45.6 | 387 | 13.65 | 76% |
| APC E 7x5 | 1 | 14.2 | 8.6 | 122 | 11040 | 52.3 | 527 | 18.59 | 72% |
| APC E 7x5 | 1 | 14.4 | 9.1 | 131 | 11250 | 53.3 | 586 | 20.67 | 72% |
| GWS RS 7x6 | 1 | 10.7 | 7.4 | 79 | 8250 | 46.9 | 405 | 14.29 | 71% |
| APC SF 8x3.8 | 1 | 6.8 | 3.7 | 25 | 5820 | 20.9 | 221 | 7.80 | 79% |
| APC SF 8x3.8 | 1 | 7.8 | 4.6 | 35 | 6480 | 23.3 | 280 | 9.88 | 77% |
| APC SF 8x3.8 | 1 | 8.8 | 5.5 | 48 | 7050 | 25.4 | 342 | 12.06 | 74% |
| APC SF 8x3.8 | 1 | 9.8 | 6.6 | 64 | 7620 | 27.4 | 410 | 14.46 | 72% |
| APC SF 8x3.8 | 1 | 10.7 | 7.55 | 80 | 8100 | 29.1 | 470 | 16.58 | 70% |
| GWS HD 8x4 | 1 | 6.8 | 3 | 20 | 6180 | 23.4 | 194 | 6.84 | 84% |
| GWS HD 8x4 | 1 | 6.8 | 3 | 20 | 6210 | 23.5 | 200 | 7.05 | 85% |
| GWS HD 8x4 | 1 | 7.8 | 3.65 | 28 | 6930 | 26.2 | 248 | 8.75 | 82% |
| GWS HD 8x4 | 1 | 7.8 | 3.55 | 27 | 6930 | 26.2 | 240 | 8.47 | 82% |
| GWS HD 8x4 | 1 | 8.8 | 4.35 | 38 | 7650 | 29.0 | 300 | 10.58 | 80% |
| GWS HD 8x4 | 1 | 8.8 | 4.2 | 36 | 7620 | 28.9 | 296 | 10.44 | 80% |
| GWS HD 8x4 | 1 | 9.7 | 5 | 48 | 8280 | 31.4 | 356 | 12.56 | 79% |
| GWS HD 8x4 | 1 | 9.8 | 5.1 | 49 | 8310 | 31.5 | 357 | 12.59 | 79% |
| GWS HD 8x4 | 1 | 10.7 | 5.85 | 62 | 8910 | 33.8 | 415 | 14.64 | 77% |
| GWS HD 8x4 | 1 | 10.7 | 5.8 | 62 | 8910 | 33.8 | 425 | 14.99 | 77% |
| GWS HD 8x4 | 1 | 14.3 | 8.9 | 127 | 10980 | 41.6 | 659 | 23.25 | 71% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 8x4 | 1 | 6.8 | 3.65 | 24 | 5940 | 22.5 | 224 | 7.90 | 81% |
| APC E 8x4 | 1 | 7.8 | 4.4 | 34 | 6630 | 25.1 | 280 | 9.88 | 79% |
| APC E 8x4 | 1 | 8.8 | 5.3 | 46 | 7290 | 27.6 | 344 | 12.13 | 77% |
| APC E 8x4 | 1 | 9.7 | 6.1 | 59 | 7830 | 29.7 | 401 | 14.14 | 75% |
| APC E 8x4 | 1 | 10.7 | 7 | 74 | 8370 | 31.7 | 468 | 16.51 | 72% |
| APC SF 8x6 | 1 | 6.8 | 5.3 | 36 | 5220 | 29.7 | 246 | 8.68 | 71% |
| APC SF 8x6 | 1 | 7.7 | 6.4 | 49 | 5730 | 32.6 | 298 | 10.51 | 69% |
| APC SF 8x6 | 1 | 8.7 | 7.5 | 65 | 6150 | 34.9 | 348 | 12.28 | 65% |
| APC SF 8x6 | 1 | 9.7 | 8.7 | 84 | 6540 | 37.2 | 394 | 13.90 | 62% |
| APC SF 8x6 | 1 | 10.6 | 9.8 | 103 | 6900 | 39.2 | 448 | 15.80 | 60% |
| APC E 8x6 | 1 | 6.8 | 4.75 | 32 | 5430 | 30.9 | 225 | 7.94 | 74% |
| APC E 8x6 | 1 | 7.8 | 5.8 | 45 | 6030 | 34.3 | 286 | 10.09 | 72% |
| APC E 8x6 | 1 | 8.7 | 6.6 | 57 | 6630 | 37.7 | 354 | 12.49 | 71% |
| APC E 8x6 | 1 | 9.7 | 7.7 | 74 | 7140 | 40.6 | 414 | 14.60 | 68% |
| APC E 8x6 | 1 | 10.7 | 8.8 | 94 | 7520 | 42.7 | 475 | 16.76 | 65% |
| APC SF 9x3.8 | 1 | 7.8 | 5.8 | 45 | 6000 | 21.6 | 345 | 12.17 | 71% |
| APC SF 9x3.8 | 1 | 8.8 | 6.9 | 60 | 6480 | 23.3 | 410 | 14.46 | 68% |
| APC SF 9x3.8 | 1 | 9.7 | 7.8 | 75 | 6930 | 24.9 | 477 | 16.83 | 66% |
| APC SF 9x3.8 | 1 | 10.7 | 9.05 | 96 | 7390 | 26.6 | 538 | 18.98 | 64% |
| APC E 9x4.5 | 1 | 6.8 | 4.6 | 31 | 5520 | 23.5 | 286 | 10.09 | 75% |
| APC E 9x4.5 | 1 | 7 | 4.75 | 33 | 5640 | 24.0 | 299 | 10.55 | 75% |
| APC E 9x4.5 | 1 | 8.7 | 6.6 | 57 | 6660 | 28.4 | 429 | 15.13 | 71% |
| APC E 9x4.5 | 1 | 9.7 | 7.7 | 74 | 7170 | 30.6 | 504 | 17.78 | 68% |
| APC E 9x4.5 | 1 | 10.7 | 8.6 | 92 | 7590 | 32.3 | 565 | 19.93 | 66% |
| APC SF 9x4.7 | 1 | 6.8 | 4.9 | 33 | 5310 | 23.6 | 281 | 9.91 | 72% |
| APC SF 9x4.7 | 1 | 7.7 | 5.9 | 45 | 5880 | 26.2 | 345 | 12.17 | 71% |
| APC SF 9x4.7 | 1 | 8.7 | 6.9 | 60 | 6420 | 28.6 | 420 | 14.82 | 68% |
| APC SF 9x4.7 | 1 | 10.7 | 8.9 | 95 | 7320 | 32.6 | 540 | 19.05 | 63% |
| GWS HD 9x5 | 1 | 6.8 | 4.7 | 31 | 5490 | 26.0 | 281 | 9.91 | 75% |
| GWS HD 9x5 | 1 | 6.8 | 4.65 | 31 | 5460 | 25.9 | 286 | 10.09 | 74% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 9x5 | 1 | 6.8 | 4.7 | 31 | 5490 | 26.0 | 281 | 9.91 | 75% |
| GWS HD 9x5 | 1 | 7.7 | 5.6 | 43 | 6060 | 28.7 | 350 | 12.35 | 73% |
| GWS HD 9x5 | 1 | 7.8 | 5.65 | 44 | 6060 | 28.7 | 347 | 12.24 | 72% |
| GWS HD 9x5 | 1 | 8.7 | 6.6 | 57 | 6570 | 31.1 | 424 | 14.96 | 70% |
| GWS HD 9x5 | 1 | 9.7 | 7.6 | 73 | 7080 | 33.5 | 488 | 17.21 | 68% |
| GWS HD 9x5 | 1 | 9.8 | 7.75 | 75 | 7110 | 33.7 | 485 | 17.11 | 67% |
| GWS HD 9x5 | 1 | 10.7 | 8.5 | 90 | 7500 | 35.5 | 550 | 19.40 | 65% |
| GWS HD 9x5 | 1 | 10.7 | 8.7 | 93 | 7530 | 35.6 | 545 | 19.22 | 65% |
| APC SF 9x6 | 1 | 6.7 | 6.75 | 45 | 4650 | 26.4 | 323 | 11.39 | 64% |
| APC SF 9x6 | 1 | 7.7 | 7.9 | 60 | 4950 | 28.1 | 375 | 13.23 | 60% |
| APC E 9x6 | 1 | 6.8 | 5.7 | 38 | 5100 | 29.0 | 305 | 10.76 | 69% |
| APC E 9x6 | 1 | 7.7 | 6.8 | 52 | 5580 | 31.7 | 371 | 13.09 | 67% |
| APC E 9x6 | 1 | 8.7 | 7.8 | 67 | 6030 | 34.3 | 442 | 15.59 | 64% |
| APC SF 10x4.7 | 1 | 6.7 | 6.7 | 44 | 4530 | 20.2 | 349 | 12.31 | 63% |
| APC SF 10x4.7 | 1 | 7.7 | 8 | 61 | 4920 | 21.9 | 416 | 14.67 | 59% |
| APC SF 10x4.7 | 1 | 8.7 | 8.9 | 77 | 5130 | 22.8 | 463 | 16.33 | 55% |
| GWS HD 10x6 | 1 | 6.7 | 5.85 | 39 | 4920 | 27.9 | 321 | 11.32 | 68% |
| GWS HD 10x6 | 1 | 7.7 | 7 | 53 | 5430 | 30.9 | 391 | 13.79 | 65% |
| GWS HD 10x6 | 1 | 8.7 | 8.2 | 71 | 5880 | 33.4 | 453 | 15.98 | 63% |
| GWS HD 10x6 | 1 | 9.6 | 9.35 | 89 | 6210 | 35.3 | 515 | 18.17 | 60% |
| GWS HD 10x6 | 1 | 10.6 | 10 | 106 | 6510 | 37.0 | 565 | 19.93 | 57% |
| APC SF 11x3.8 | 1 | 6.9 | 7.5 | 51 | 4560 | 16.4 | 411 | 14.50 | 61% |
| GWS HD 11x7 | 1 | 6.9 | 8.05 | 55 | 4350 | 28.8 | 416 | 14.67 | 58% |
