Motrolfly - 2210-1050
Specifications
- Type: Outrunner
- Weight: 46.00g (1.62oz)
- Maximum Amps: 14
Constants
- kV: 970
- Rm: 0.35
- Io: 0.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.6 | 9480 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 2.6 | 17 | 5910 | 22.4 | 185 | 6.53 | 88% |
| GWS HD 8x4 | 1 | 7.9 | 3.15 | 24 | 6690 | 25.3 | 233 | 8.22 | 87% |
| GWS HD 8x4 | 1 | 8.9 | 3.8 | 33 | 7410 | 28.1 | 295 | 10.41 | 86% |
| GWS HD 8x4 | 1 | 9.9 | 4.4 | 43 | 8100 | 30.7 | 357 | 12.59 | 84% |
| GWS HD 8x4 | 1 | 10.8 | 5.15 | 55 | 8640 | 32.7 | 421 | 14.85 | 82% |
| GWS HD 8x4 | 1 | 14.6 | 8.3 | 121 | 11190 | 42.4 | 705 | 24.87 | 79% |
| GWS RS 8x4.3 | 1 | 6.9 | 3.4 | 23 | 5700 | 23.2 | 230 | 8.11 | 85% |
| GWS RS 8x4.3 | 1 | 7.9 | 4.1 | 32 | 6390 | 26.0 | 290 | 10.23 | 83% |
| GWS RS 8x4.3 | 1 | 8.9 | 4.85 | 43 | 7050 | 28.7 | 350 | 12.35 | 82% |
| GWS RS 8x4.3 | 1 | 9.9 | 5.7 | 56 | 7680 | 31.3 | 420 | 14.82 | 80% |
| GWS RS 8x4.3 | 1 | 10.9 | 6.5 | 70 | 8280 | 33.7 | 485 | 17.11 | 78% |
| GWS HD 8x6 | 1 | 6.9 | 4 | 27 | 5580 | 31.7 | 221 | 7.80 | 83% |
| GWS HD 8x6 | 1 | 7.9 | 4.85 | 38 | 6150 | 34.9 | 272 | 9.59 | 80% |
| GWS HD 8x6 | 1 | 8.9 | 5.8 | 51 | 6750 | 38.4 | 330 | 11.64 | 78% |
| GWS HD 8x6 | 1 | 9.9 | 6.85 | 67 | 7350 | 41.8 | 392 | 13.83 | 77% |
| GWS HD 8x6 | 1 | 10.9 | 7.85 | 85 | 7890 | 44.8 | 452 | 15.94 | 75% |
| APC SF 8x6 | 1 | 6.9 | 4.8 | 33 | 5250 | 29.8 | 266 | 9.38 | 78% |
| APC SF 8x6 | 1 | 7.9 | 5.95 | 47 | 5790 | 32.9 | 330 | 11.64 | 76% |
| APC SF 8x6 | 1 | 8.9 | 7.1 | 63 | 6300 | 35.8 | 397 | 14.00 | 73% |
| APC SF 8x6 | 1 | 9.8 | 8.3 | 81 | 6780 | 38.5 | 464 | 16.37 | 71% |
| APC SF 8x6 | 1 | 10.8 | 9.6 | 103 | 7230 | 41.1 | 530 | 18.70 | 69% |
| APC E 8x6 | 1 | 6.9 | 4.4 | 30 | 5430 | 30.9 | 216 | 7.62 | 81% |
| APC E 8x6 | 1 | 7.9 | 5.4 | 42 | 6030 | 34.3 | 270 | 9.52 | 79% |
| APC E 8x6 | 1 | 8.9 | 6.4 | 56 | 6540 | 37.2 | 325 | 11.46 | 76% |
| APC E 8x6 | 1 | 9.9 | 7.5 | 74 | 7110 | 40.4 | 378 | 13.33 | 74% |
| APC E 8x6 | 1 | 10.9 | 8.65 | 94 | 7590 | 43.1 | 439 | 15.49 | 72% |
| GWS RS 8x6 | 1 | 6.9 | 4 | 27 | 5520 | 31.4 | 245 | 8.64 | 82% |
| GWS RS 8x6 | 1 | 7.9 | 4.9 | 38 | 6150 | 34.9 | 308 | 10.86 | 80% |
| GWS RS 8x6 | 1 | 8.9 | 5.9 | 52 | 6750 | 38.4 | 374 | 13.19 | 78% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 8x6 | 1 | 9.9 | 6.8 | 67 | 7290 | 41.4 | 435 | 15.34 | 76% |
| GWS RS 8x6 | 1 | 10.8 | 7.95 | 85 | 7770 | 44.1 | 503 | 17.74 | 74% |
| APC SF 9x4.7 | 1 | 6.9 | 4.6 | 31 | 5310 | 23.6 | 303 | 10.69 | 79% |
| APC SF 9x4.7 | 1 | 7.9 | 5.65 | 44 | 5910 | 26.3 | 384 | 13.55 | 77% |
| APC SF 9x4.7 | 1 | 8.9 | 6.7 | 59 | 6450 | 28.7 | 466 | 16.44 | 75% |
| APC SF 9x4.7 | 1 | 9.8 | 7.7 | 75 | 6960 | 31.0 | 538 | 18.98 | 73% |
| APC SF 9x4.7 | 1 | 10.8 | 8.8 | 95 | 7500 | 33.4 | 623 | 21.98 | 72% |
| GWS HD 9x5 | 1 | 6.9 | 4.3 | 29 | 5460 | 25.9 | 294 | 10.37 | 82% |
| GWS HD 9x5 | 1 | 7.9 | 5.3 | 41 | 6090 | 28.8 | 368 | 12.98 | 79% |
| GWS HD 9x5 | 1 | 8.9 | 6.25 | 55 | 6660 | 31.5 | 450 | 15.87 | 77% |
| GWS HD 9x5 | 1 | 9.9 | 7.25 | 71 | 7170 | 34.0 | 530 | 18.70 | 75% |
| GWS HD 9x5 | 1 | 10.9 | 8.4 | 91 | 7710 | 36.5 | 620 | 21.87 | 73% |
| APC SF 9x6 | 1 | 6.9 | 6.5 | 44 | 4770 | 27.1 | 337 | 11.89 | 71% |
| APC SF 9x6 | 1 | 7.9 | 7.95 | 62 | 5190 | 29.5 | 408 | 14.39 | 68% |
| APC SF 9x6 | 1 | 8.9 | 9.45 | 84 | 5550 | 31.5 | 482 | 17.00 | 64% |
| APC SF 9x6 | 1 | 9.8 | 10.8 | 105 | 5850 | 33.2 | 542 | 19.12 | 62% |
| APC SF 9x6 | 1 | 10.8 | 12.2 | 131 | 6150 | 34.9 | 597 | 21.06 | 59% |
| GWS HD 9x7.5 | 1 | 6.9 | 6.25 | 43 | 4860 | 34.5 | 282 | 9.95 | 73% |
| GWS HD 9x7.5 | 1 | 7.4 | 6.95 | 51 | 5100 | 36.2 | 313 | 11.04 | 71% |
| GWS HD 9x7.5 | 1 | 7.9 | 7.6 | 60 | 5340 | 37.9 | 343 | 12.10 | 70% |
| GWS HD 9x7.5 | 1 | 8.9 | 8.9 | 79 | 5760 | 40.9 | 407 | 14.36 | 67% |
| GWS HD 9x7.5 | 1 | 9.9 | 10.3 | 101 | 6150 | 43.7 | 463 | 16.33 | 64% |
| GWS HD 10x6 | 1 | 6.9 | 5.65 | 38 | 5040 | 28.6 | 361 | 12.73 | 75% |
| GWS HD 10x6 | 1 | 7.9 | 6.85 | 54 | 5580 | 31.7 | 441 | 15.56 | 73% |
| GWS HD 10x6 | 1 | 8.9 | 8.05 | 71 | 6060 | 34.4 | 526 | 18.55 | 70% |
| GWS HD 10x6 | 1 | 9.9 | 9.3 | 92 | 6510 | 37.0 | 611 | 21.55 | 68% |
| GWS HD 10x6 | 1 | 10.9 | 10.5 | 114 | 6900 | 39.2 | 689 | 24.30 | 65% |
