Turnigy - SK3 2826-1130
Specifications
- Type: Outrunner
- Weight: 45.00g (1.59oz)
- Diameter: 27.80mm (1.09in)
- Length: 27.80mm (1.09in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 14
Constants
- kV: 1120
- Rm: 0.25
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.65 | 7575 |
| 8 | 0.7 | 8650 |
| 10 | 0.85 | 10960 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 3.8 | 26 | 6750 | 25.6 | 237 | 8.36 | 87% |
| GWS HD 8x4 | 1 | 7.8 | 4.6 | 35 | 7530 | 28.5 | 301 | 10.62 | 86% |
| GWS HD 8x4 | 1 | 8.8 | 5.45 | 47 | 8340 | 31.6 | 369 | 13.02 | 85% |
| GWS HD 8x4 | 1 | 9.8 | 6.4 | 62 | 9090 | 34.4 | 445 | 15.70 | 83% |
| GWS HD 8x4 | 1 | 10.8 | 7.7 | 83 | 9960 | 37.7 | 540 | 19.05 | 82% |
| GWS HD 9x5 | 1 | 6.8 | 6 | 40 | 6060 | 28.7 | 358 | 12.63 | 80% |
| GWS HD 9x5 | 1 | 7.8 | 7.35 | 57 | 6750 | 32.0 | 452 | 15.94 | 77% |
| GWS HD 9x5 | 1 | 8.8 | 8.9 | 78 | 7470 | 35.4 | 540 | 19.05 | 76% |
| GWS HD 9x5 | 1 | 9.8 | 10.2 | 99 | 8010 | 37.9 | 645 | 22.75 | 73% |
| GWS HD 9x5 | 1 | 10.7 | 11.65 | 124 | 8550 | 40.5 | 726 | 25.61 | 71% |
| GWS HD 10x6 | 1 | 6.7 | 7.7 | 51 | 5640 | 32.0 | 429 | 15.13 | 75% |
| GWS HD 10x6 | 1 | 7.7 | 9.25 | 71 | 6180 | 35.1 | 524 | 18.48 | 72% |
| GWS HD 10x6 | 1 | 8.7 | 10.8 | 93 | 6720 | 38.2 | 610 | 21.52 | 69% |
| GWS HD 10x6 | 1 | 9.6 | 12.35 | 118 | 7200 | 40.9 | 708 | 24.97 | 67% |
| GWS HD 10x6 | 1 | 10.6 | 14 | 148 | 7650 | 43.5 | 793 | 27.97 | 64% |
| GWS HD 11x7 | 1 | 6.8 | 10.7 | 72 | 4920 | 32.6 | 540 | 19.05 | 65% |
| GWS HD 11x7 | 1 | 7.7 | 12.6 | 97 | 5310 | 35.2 | 641 | 22.61 | 62% |
| GWS HD 11x7 | 1 | 8.7 | 14.1 | 122 | 5700 | 37.8 | 711 | 25.08 | 58% |
| GWS HD 11x7 | 1 | 9.7 | 16.1 | 156 | 6030 | 40.0 | 820 | 28.92 | 56% |
| GWS HD 11x7 | 1 | 10.6 | 17.5 | 185 | 6210 | 41.2 | 865 | 30.51 | 52% |
