KEDA - TR2834/18
Specifications
- Type: Outrunner
- Weight: 71.00g (2.50oz)
- Diameter: 28.00mm (1.10in)
- Length: 34.00mm (1.34in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 1020
- Rm: 0.204
- Io: 0.9
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.75 | 6900 |
| 8 | 0.8 | 7830 |
| 10 | 0.9 | 10000 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 3.35 | 23 | 6420 | 24.3 | 216 | 7.62 | 91% |
| GWS HD 8x4 | 1 | 7.9 | 4.05 | 31 | 7230 | 27.4 | 277 | 9.77 | 90% |
| GWS HD 8x4 | 1 | 8.9 | 4.8 | 42 | 7950 | 30.1 | 340 | 11.99 | 88% |
| GWS HD 8x4 | 1 | 9.9 | 5.7 | 56 | 8760 | 33.2 | 413 | 14.57 | 87% |
| GWS HD 8x4 | 1 | 10.8 | 6.75 | 72 | 9600 | 36.4 | 501 | 17.67 | 87% |
| GWS HD 9x5 | 1 | 6.8 | 5.4 | 36 | 5970 | 28.3 | 340 | 11.99 | 86% |
| GWS HD 9x5 | 1 | 7.8 | 6.6 | 51 | 6660 | 31.5 | 432 | 15.24 | 84% |
| GWS HD 9x5 | 1 | 8.8 | 7.75 | 68 | 7290 | 34.5 | 517 | 18.24 | 81% |
| GWS HD 9x5 | 1 | 9.8 | 9.2 | 90 | 7980 | 37.8 | 624 | 22.01 | 80% |
| GWS HD 9x5 | 1 | 10.8 | 10.6 | 114 | 8610 | 40.8 | 735 | 25.93 | 78% |
| GWS HD 9x5 | 1 | 13.5 | 15.25 | 205 | 10230 | 48.4 | 1066 | 37.60 | 74% |
| GWS HD 10x6 | 1 | 6.9 | 7.3 | 50 | 5640 | 32.0 | 435 | 15.34 | 80% |
| GWS HD 10x6 | 1 | 7.8 | 8.8 | 68 | 6240 | 35.5 | 534 | 18.84 | 78% |
| GWS HD 10x6 | 1 | 8.8 | 10.35 | 91 | 6810 | 38.7 | 641 | 22.61 | 76% |
| GWS HD 10x6 | 1 | 9.8 | 12.1 | 118 | 7380 | 41.9 | 757 | 26.70 | 74% |
| GWS HD 10x6 | 1 | 10.7 | 13.75 | 147 | 7860 | 44.7 | 864 | 30.48 | 72% |
| GWS HD 10x8 | 1 | 6.8 | 10.55 | 71 | 4980 | 37.7 | 430 | 15.17 | 72% |
| GWS HD 10x8 | 1 | 7.7 | 12.65 | 97 | 5490 | 41.6 | 520 | 18.34 | 70% |
| GWS HD 10x8 | 1 | 8.7 | 14.75 | 128 | 5880 | 44.5 | 612 | 21.59 | 66% |
| GWS HD 10x8 | 1 | 9.6 | 16.55 | 158 | 6270 | 47.5 | 676 | 23.85 | 64% |
| GWS HD 10x8 | 1 | 10.6 | 18.5 | 196 | 6630 | 50.2 | 759 | 26.77 | 61% |
| GWS HD 11x7 | 1 | 6.8 | 9.9 | 67 | 5070 | 33.6 | 556 | 19.61 | 73% |
| GWS HD 11x7 | 1 | 7.8 | 12 | 93 | 5610 | 37.2 | 683 | 24.09 | 71% |
| GWS HD 11x7 | 1 | 8.7 | 13.8 | 120 | 6030 | 40.0 | 794 | 28.01 | 68% |
| GWS HD 11x7 | 1 | 9.7 | 15.9 | 154 | 6480 | 43.0 | 920 | 32.45 | 65% |
| GWS HD 11x7 | 1 | 10.6 | 17.9 | 189 | 6840 | 45.3 | 1039 | 36.65 | 63% |
