GPS - HXT C2028-20
Specifications
- Type: Outrunner
- Weight: 25.00g (0.88oz)
- Maximum Amps: 10
Constants
- kV: 1480
- Rm: 0.73
- Io: 0.4
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.3 | 10080 |
| 8 | 0.35 | 11460 |
| 10 | 0.4 | 14250 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 7 | 1.25 | 8 | 9180 | 34.8 | 47 | 1.66 | 89% |
| GWS HD 4x4 | 1 | 7.4 | 1.3 | 9 | 9660 | 36.6 | 52 | 1.83 | 88% |
| GWS HD 4x4 | 1 | 8 | 1.45 | 11 | 10290 | 39.0 | 59 | 2.08 | 87% |
| GWS HD 4x4 | 1 | 9 | 1.75 | 15 | 11370 | 43.1 | 72 | 2.54 | 85% |
| GWS HD 4x4 | 1 | 10 | 2.05 | 20 | 12510 | 47.4 | 87 | 3.07 | 85% |
| GWS HD 4x4 | 1 | 11 | 2.3 | 25 | 13560 | 51.4 | 102 | 3.60 | 83% |
| GWS HD 6x3 | 1 | 7 | 1.75 | 12 | 8610 | 24.5 | 104 | 3.67 | 83% |
| GWS HD 6x3 | 1 | 7.4 | 1.95 | 14 | 9060 | 25.7 | 115 | 4.06 | 83% |
| GWS HD 6x3 | 1 | 7.9 | 2.1 | 16 | 9600 | 27.3 | 127 | 4.48 | 82% |
| GWS HD 6x3 | 1 | 8.9 | 2.55 | 22 | 10530 | 29.9 | 150 | 5.29 | 80% |
| GWS HD 6x3 | 1 | 9.9 | 2.9 | 28 | 11430 | 32.5 | 196 | 6.91 | 78% |
| GWS HD 6x3 | 1 | 10.9 | 3.4 | 37 | 12330 | 35.0 | 229 | 8.08 | 76% |
| GWS HD 7x3.5 | 1 | 6.9 | 2.45 | 16 | 7860 | 26.1 | 140 | 4.94 | 77% |
| GWS HD 7x3.5 | 1 | 7.4 | 2.7 | 19 | 8250 | 27.3 | 156 | 5.50 | 75% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.95 | 23 | 8670 | 28.7 | 176 | 6.21 | 74% |
| GWS HD 7x3.5 | 1 | 9 | 3.45 | 31 | 9510 | 31.5 | 215 | 7.58 | 71% |
| GWS HD 7x3.5 | 1 | 9.9 | 4 | 39 | 10200 | 33.8 | 254 | 8.96 | 70% |
| GWS HD 7x3.5 | 1 | 10.9 | 4.5 | 49 | 10890 | 36.1 | 291 | 10.26 | 68% |
| APC SF 7x4 | 1 | 7 | 3.55 | 24 | 6720 | 25.4 | 174 | 6.14 | 65% |
| APC SF 7x4 | 1 | 7.4 | 3.8 | 28 | 6960 | 26.4 | 188 | 6.63 | 64% |
| APC SF 7x4 | 1 | 7.9 | 4.15 | 32 | 7200 | 27.3 | 204 | 7.20 | 62% |
| APC SF 7x4 | 1 | 8.9 | 4.9 | 43 | 7860 | 29.8 | 244 | 8.61 | 60% |
| APC SF 7x4 | 1 | 9.9 | 5.5 | 54 | 8250 | 31.2 | 272 | 9.59 | 56% |
