GWS - 2212/13T
Specifications
- Type: Outrunner
- Weight: 49.00g (1.73oz)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 10
Constants
- kV: 1030
- Rm: 0
- Io: 0
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 7.9 | 0.55 | 0 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 14.7 | 5.3 | 77 | 13620 | 45.1 | 453 | 15.98 | 90% |
| GWS RS 7x6 | 1 | 11.1 | 8.35 | 92 | 8940 | 50.8 | 464 | 16.37 | 78% |
| GWS HD 8x4 | 1 | 11.1 | 6.5 | 72 | 9600 | 36.4 | 481 | 16.97 | 84% |
| GWS HD 8x6 | 1 | 11.1 | 9.9 | 109 | 8400 | 47.7 | 502 | 17.71 | 73% |
| GWS RS 9x4.7 | 1 | 11.1 | 11.75 | 130 | 7650 | 34.0 | 684 | 24.13 | 67% |
| GWS HD 9x5 | 1 | 6.9 | 5.15 | 35 | 5790 | 27.4 | 325 | 11.46 | 81% |
| GWS HD 9x5 | 1 | 7.9 | 6.35 | 50 | 6480 | 30.7 | 407 | 14.36 | 80% |
| GWS HD 9x5 | 1 | 8.9 | 7.45 | 66 | 7020 | 33.2 | 488 | 17.21 | 77% |
| GWS HD 9x5 | 1 | 9.9 | 8.8 | 87 | 7590 | 35.9 | 575 | 20.28 | 74% |
| GWS HD 9x5 | 1 | 10.9 | 9.85 | 107 | 8070 | 38.2 | 651 | 22.96 | 72% |
| GWS RS 10x4.7 | 1 | 7.4 | 8.75 | 64 | 4920 | 21.9 | 464 | 16.37 | 65% |
| GWS HD 10x6 | 1 | 6.9 | 6.6 | 45 | 5340 | 30.3 | 380 | 13.40 | 75% |
| GWS HD 10x6 | 1 | 7.4 | 7.2 | 53 | 5580 | 31.7 | 424 | 14.96 | 73% |
| GWS HD 10x6 | 1 | 7.9 | 7.9 | 62 | 5850 | 33.2 | 460 | 16.23 | 72% |
| GWS HD 10x6 | 1 | 8.9 | 9.25 | 82 | 6360 | 36.1 | 538 | 18.98 | 69% |
| GWS HD 10x6 | 1 | 9.9 | 10.6 | 104 | 6750 | 38.4 | 624 | 22.01 | 66% |
| GWS HD 10x6 | 1 | 10.9 | 12.1 | 131 | 7170 | 40.7 | 704 | 24.83 | 64% |
| GWS RS 11x4.7 | 1 | 7.4 | 10.05 | 74 | 4680 | 20.8 | 518 | 18.27 | 61% |
| GWS HD 11x7 | 1 | 7.4 | 9.6 | 71 | 4830 | 32.0 | 508 | 17.92 | 63% |
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 6x3 | 1 | 7.7 | 1.5 | 11 | 7555 | 21.5 | 86 | 3.03 | 95% |
| GWS EP 7x6 | 1 | 7.4 | 4.4 | 32 | 6343 | 36.0 | 224 | 7.90 | 83% |
| GWS EP 8x4 | 1 | 7.4 | 3.4 | 25 | 6632 | 25.1 | 232 | 8.18 | 87% |
| GWS EP 8x4 | 1 | 10.9 | 6.4 | 69 | 9293 | 35.2 | 472 | 16.65 | 83% |
| GWS HD 8x6 | 1 | 7.1 | 5 | 35 | 5948 | 33.8 | 252 | 8.89 | 81% |
| GWS HD 8x6 | 1 | 10.5 | 9.1 | 95 | 8064 | 45.8 | 481 | 16.97 | 75% |
| GWS EP 8x6 | 1 | 7.3 | 5.5 | 40 | 5905 | 33.5 | 293 | 10.34 | 79% |
| GWS EP 9x4.7 | 1 | 7.2 | 5.7 | 41 | 5819 | 25.9 | 334 | 11.78 | 78% |
| GWS EP 9x5 | 1 | 7.1 | 5.3 | 37 | 5835 | 27.6 | 331 | 11.68 | 80% |
| GWS EP 9x5 | 1 | 10.5 | 9.7 | 101 | 7912 | 37.5 | 625 | 22.05 | 73% |
| APC SF 9x6 | 1 | 6.7 | 7.9 | 52 | 4682 | 26.6 | 349 | 12.31 | 68% |
| GWS EP 9x7 | 1 | 6.9 | 7.9 | 54 | 4852 | 32.2 | 343 | 12.10 | 68% |
| GWS EP 3 blade 9x7 | 1 | 7 | 7.9 | 55 | 4923 | 32.6 | 351 | 12.38 | 68% |
| GWS HD 9x7.5 | 1 | 6.9 | 7.3 | 50 | 5069 | 36.0 | 300 | 10.58 | 71% |
| GWS HD 9x7.5 | 1 | 10 | 12.4 | 124 | 6494 | 46.1 | 523 | 18.45 | 63% |
| APC SF 10x4.7 | 1 | 6.7 | 7.8 | 52 | 4781 | 21.3 | 417 | 14.71 | 69% |
| GWS EP 10x4.7 | 1 | 6.8 | 8.1 | 55 | 4685 | 20.9 | 423 | 14.92 | 67% |
| GWS EP 10x6 | 1 | 7 | 6.9 | 48 | 5285 | 30.0 | 387 | 13.65 | 73% |
| GWS EP 10x6 | 1 | 10.2 | 11.8 | 120 | 6819 | 38.7 | 680 | 23.99 | 65% |
| GWS EP 10x8 | 1 | 6.5 | 9.6 | 62 | 4072 | 30.9 | 392 | 13.83 | 61% |
| GWS EP 11x4.7 | 1 | 6.7 | 9.2 | 61 | 4306 | 19.2 | 459 | 16.19 | 62% |
